An inductor is connected to a 18 kHz oscillator. The peak current is 69 mA when...

Question

Question

An inductor is connected to a 18 kHz oscillator. The peak current is 69 mA when the rms voltage is 5.8 V .

Part A

What is the value of the inductance L?

Express your answer to two significant figures and include the appropriate units.

L

=

1.05•10−3H

SubmitPrevious AnswersRequest Answer

Incorrect; Try Again; 4 attempts remaining

Review your calculations; you may have made a rounding error or used the wrong number of significant figures.

science physics

Answer 1

Answer #1

Answer 2
