A 4.00 m long rod with a mass of 1.45 kg is pinned in place at...

A 4.00 m long rod with a mass of 1.45 kg is pinned in place at one end and has a 5.50 kg point mass located at the other end. The rod is allowed to rotate about the pinned end. If the rod spins with a speed of 3.80 rad/s, how much kinetic energy does the rod have?

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
