A R-C circuit has a maximum current of 1.8mA. Time constant 0.667s. Capacitor store 4J of...

Question

Question

A R-C circuit has a maximum current of 1.8mA.

Time constant 0.667s.

Capacitor store 4J of energy.

Find V(battery), R, C?

science physics

Answer 1

Answer #1

Answer 2
