A ballistic pendulum, as shown in the figure, was a device used in the past century...
A ballistic pendulum, as shown in the figure, was a device used in the past century to measure the speed of bullets. The pendulum consists of a large block of wood suspended from long wires. Initially, the pendulum is at rest. The bullet strikes the block horizontally and remains stuck in it. The impact of the bullet puts the block in motion, causing it to swing upward to a height h. If the bullet has a mass of 12.8 g, and the block of mass 6.0 kgswings up to a height of h = 20.000 cm, what was the speed of the bullet before impact?
Homework Answers
Add Answer to:
A ballistic pendulum, as shown in the figure, was a device used
in the past century...
Problem 3 A "ballistic pendulum" is a device (now largely obsolete, but very useful in its...
Problem 3 A "ballistic pendulum" is a device (now largely obsolete, but very useful in its day) to measure the speed of a bullet as it hits a target. Let the target be a block of wood suspended from a string, as in the figure below. When the bullet hits, it is embedded in the wood, and together they swing, like a pendulum, to some maximum height h. The question is, how do you find the initial speed of the...
Find the initial sped of the bullet, v1i The ballistic pendulum is a device used to...
Find the initial sped of the bullet, v1i
The ballistic pendulum is a device used to measure the speed of a fast-moving projectile such a bullet. The bullet is fired into a large block of wood suspended from some light wires. The bullet is stopped by the block, and the entire system swings up to a height h. it possible to obtain the initial speed of the bullet by measuring h and the two masses. As an example of the...
A ballistic pendulum is used to measure the speed of bullets. In these experiments, a bullet...
A ballistic pendulum is used to measure the speed of bullets. In these experiments, a bullet is fired into a large block suspended by wires. The bullet is embedded in the block and the collision is inelastic. After the impact, the block swings forward and rises. a. If a 2.1-g bullet is fired at 440 m/s into a 4.0 kg block, how far will it swing up? (what is the maximum vertical displacement of the block?) b. Find an equation...
3. The ballistic pendulum is a device used to measure the speed of a projectile, such...
3. The ballistic pendulum is a device used to measure the speed of a projectile, such as a bullet. The projectile, of mass m, is fired into a large block of mass M, which is suspended like a pendulum. As a result of the collision, the pendulum and projectile together swing up to a maximum height h. Determine the relationship between the initial horizontal speed of the projectile, v, and the maximum heighth
A ballistic pendulum is a device that is used to determine the muzzle velocity of the...
A ballistic pendulum is a device that is used to determine the muzzle velocity of the bullet shot by a hunting rifle, for example. As you know, the velocity of the bullet fired by a rifle dictates the distance it can travel. Those who reload their own bullets may find this device helpful. When a bullet is fired broadside into a suspended 4x4 chunk of wood, the wood swings up from rest by an angle of 60 degrees. Together, the...
A ballistic pendulum is a device that is used to determine the muzzle velocity of the...
A ballistic pendulum is a device that is used to determine the muzzle velocity of the bullet shot by a hunting rifle, for example. As you know, the velocity of the bullet fired by a rifle dictates the distance it can travel. Those who reload their own bullets may find this device helpful. When a bullet is fired broadside into a suspended 4x4 chunk of wood, the wood swings up from rest by an angle of 60 degrees. Together, the...
detail information please 11. The ballistic pendulum (see the figure below) is a device used to...
detail information please
11. The ballistic pendulum (see the figure below) is a device used to measure the speed of a fast-moving projectile such as a bullet. The bullet is fired into a large block of wood suspended from some light wires. The bullet is stopped by the block, and the entire system swings up to a height h. m+m V1i 2 (a) Determine the ratio of the momentum immediately after the collision to the momentum immediately before the collision...
The ballistic pendulum is an apparatus used to measure the speed of a fast-moving projectile such...
The ballistic pendulum is an apparatus used to measure the speed of a fast-moving projectile such as a bullet. A projectile of mass ml-20 g (vl-30 m/s) is fired into a large block of wood of mass m2-40 g suspended from some light wires. The projectile cmbeds in the block, and the entire system swings through a height h. How can we determine the height h? VIA St
The ballistic pendulum is a simple device—the pendulum part consists of a wooden block, which has...
The ballistic pendulum is a simple device—the pendulum part consists of a wooden block, which has a mass of 860. grams, hanging from a string. The block is initially at rest. However, a bullet with a mass of 18.0 grams is fired at the block. The bullet embeds itself in the block, and the bullet and block then oscillate back and forth on the string, pendulum style, after the collision. Just before impact with the block, the bullet's velocity is...
Please help me with this. thank you Prob3: In a system of ballistic pendulum, a bullet...
Please help me with this. thank you
Prob3: In a system of ballistic pendulum, a bullet of mass 5.0 g makes a completely inelastic collision with a block of mass of wood of mass 2.0 kg which is suspended like a pendulum. After the impact, the block swings up to maximum height of 3.0 m. What is the initial speed of the bullet?
Problem 3 A "ballistic pendulum" is a device (now largely obsolete, but very useful in its day) to measure the speed of a bullet as it hits a target. Let the target be a block of wood suspended from a string, as in the figure below. When the bullet hits, it is embedded in the wood, and together they swing, like a pendulum, to some maximum height h. The question is, how do you find the initial speed of the...
Find the initial sped of the bullet, v1i
The ballistic pendulum is a device used to measure the speed of a fast-moving projectile such a bullet. The bullet is fired into a large block of wood suspended from some light wires. The bullet is stopped by the block, and the entire system swings up to a height h. it possible to obtain the initial speed of the bullet by measuring h and the two masses. As an example of the...
3. The ballistic pendulum is a device used to measure the speed of a projectile, such as a bullet. The projectile, of mass m, is fired into a large block of mass M, which is suspended like a pendulum. As a result of the collision, the pendulum and projectile together swing up to a maximum height h. Determine the relationship between the initial horizontal speed of the projectile, v, and the maximum heighth
detail information please
11. The ballistic pendulum (see the figure below) is a device used to measure the speed of a fast-moving projectile such as a bullet. The bullet is fired into a large block of wood suspended from some light wires. The bullet is stopped by the block, and the entire system swings up to a height h. m+m V1i 2 (a) Determine the ratio of the momentum immediately after the collision to the momentum immediately before the collision...
The ballistic pendulum is an apparatus used to measure the speed of a fast-moving projectile such as a bullet. A projectile of mass ml-20 g (vl-30 m/s) is fired into a large block of wood of mass m2-40 g suspended from some light wires. The projectile cmbeds in the block, and the entire system swings through a height h. How can we determine the height h? VIA St
Please help me with this. thank you
Prob3: In a system of ballistic pendulum, a bullet of mass 5.0 g makes a completely inelastic collision with a block of mass of wood of mass 2.0 kg which is suspended like a pendulum. After the impact, the block swings up to maximum height of 3.0 m. What is the initial speed of the bullet?
