A magnetic field of 0.228 T exists in the region enclosed by a solenoid that has...

A magnetic field of 0.228 T exists in the region enclosed by a solenoid that has 455 turns and a diameter of 9.54 cm. Within what period of time must the field be reduced to zero if the average magnitude of the induced emf within the coil during this time interval is to be 12.6 kV? Answer in units of s.

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
A magnetic field of 0.228 T exists in the region enclosed by a solenoid that has...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • Pregunta 4 (10 puntos) A magnetic field of 0.200 T exists within a solenoid of 500...

    Pregunta 4 (10 puntos) A magnetic field of 0.200 T exists within a solenoid of 500 turns and a diameter of 10.0 cm. How rapidly (that is, within what period of time) must the field be reduced to zero if the average induced emf within the coil during this time interval is to be 10.0 kV?

  • The figure shows a long solenoid S with a shorter, smaller solenoid C inside it. The...

    The figure shows a long solenoid S with a shorter, smaller solenoid C inside it. The smaller solenoid has 150 turns and a diameter of 2 cm The larger solenoid S has 300 turns/cm and a radius of 3.5 cm. Axis At t = 0 the current in S is 2.5 A. It comes out at the top and goes in at the bottom, as shown in the figure. (a) What is the magnitude and direction of the magnetic field...

  • Long solenoid has 210 turns/cm and carries a current i = 1.5A; its radius is 1.8...

    Long solenoid has 210 turns/cm and carries a current i = 1.5A; its radius is 1.8 cm. A coil of 129 turns and diameter 6.7 cm is placed outside the solenoid as shown in the figure. If the current in the solenoid is decreased to zero during 25 ms, what is the magnitude of the emf induced in the coil during this time interval? Coil OO Solenoid Select one a 208.02 mv C 5.5.59 mv OC 1.61 mv O d....

  • The magnetic field inside the solenoid in the figure changes at the rate of 4.5 T/s....

    The magnetic field inside the solenoid in the figure changes at the rate of 4.5 T/s. A conducting coil with 2000 turns surrounds the solenoid, as shown. The radius of the solenoid is 5 cm, and the radius of the coil is 8 cm. What is the potential difference induced in the coil?

  • a) The magnetic field is a certain region varies with time given by B(t) =30e^ -2t...

    a) The magnetic field is a certain region varies with time given by B(t) =30e^ -2t in Tesla. A 10cm * 15cm rectangular coil whose plane is perpendicular to the direction of the magnetic is placed in this field, find the magnetic flux as a function of time flux(t). b) A coil consists of 200 turns of wire. Each turn is a square of side d=18cm, and a uniform magnetic field directed perpendicular to the plane of the coil is...

  • A square loop of wire with a small resistance is moved with constant speed from a...

    A square loop of wire with a small resistance is moved with constant speed from a field free region into a region of uniform B field (B is constant in time) and then back into a field free region to the left. The self inductance of the loop is negligible. When entering the field the coil experiences a magnetic force to the left. When leaving the field the coil experiences a magnetic force to the right. Upon entering the field,...

  • 4. A 500-turn solenoid has a length of 10.0 cm and a radius of 1.00 cm....

    4. A 500-turn solenoid has a length of 10.0 cm and a radius of 1.00 cm. (a) If you are facing the opening in the front of the solenoid, what current would be needed in the solenoid (magnitude and direction) to generate a magnetic field of 2.51 x 10T pointing directly towards you? (6) A second coil of ten turns is wrapped tightly around the solenoid, so it can be considered to have the same radius as the solenoid. The...

  • 5) A solenoid comprises 500,000 turns of wire and is 10 cm long and 1.0 cm...

    5) A solenoid comprises 500,000 turns of wire and is 10 cm long and 1.0 cm in radius. a) Find the resultant magnetic field inside the coil if a current of 1 μA flows through the wire. b) How would this change if the core is filled with mumetal (μ = 300 μ0 ). 6) The solenoid of Q5 is placed in a region where the perpendicular magnetic field strength is varying sinusoidally by 20 μT at a rate of...

  • For this time, calculate the average magnetic flux through each turn of the inner solenoid. A...

    For this time, calculate the average magnetic flux through each turn of the inner solenoid. A solenoidal coil with 27 turns of wire is wound tightly around another coil with 320 turns. The inner solenold is 22.0 cm long and has a diameter of 2.00 cm. At a certain time, the current in the inner solenoid is 0.130 A and is increasing at a rate of 1800 A/s Submit RequestAnswer Part B For this time, calculate the mutual inductance of...

  • 3. + ㅢ10 points TiplerG 28P032 A solenoid of length 25 cm and radius 0.8 cm...

    3. + ㅢ10 points TiplerG 28P032 A solenoid of length 25 cm and radius 0.8 cm with 375 turns is in an external magnetic field of 580 G that makes an angle of 50° with the axis of the solenoid (a) Find the magnetic flux through the solenoid mWb (b) Find the magnitude of the emf induced in the solenoid if the external magnetic field is reduced to zero in 1.4 s mV
