A 200-loop coil of cross sectional area 0.50 m2 lies in the plane of this paper....
A 200-loop coil of cross sectional area 0.50 m2 lies in the plane of this paper. Directed out of the paper is a magnetic field of 0.080 T. The field out of the paper decreases to 0.020 T in 25 ms (milli-second). What is the average EMF in the coil as the flux is changing?
a-60 V
b-80 V
c-50 V
d-70 V
e-90 V
Homework Answers
Add Answer to:
A 200-loop coil of cross sectional area 0.50 m2 lies
in the plane of this paper....
A square loop of wire of area A lies in the plane of the paper. The...
A square loop of wire of area A lies in the plane of the paper. The field changes at constant rate and after time T is directed out of the paper with the same magnitude it originally had inward. The magnitude of the change of flux through the coil in time T was (a) 2BA (b) BA (c) %BA (d) 4 BA (e) Zero
A circular loop in the plane of the paper lies in a 0.65 T magnetic field...
A circular loop in the plane of the paper lies in a 0.65 T magnetic field pointing into the paper. The resistance of the coil is 2.20 Ω. If the loop's diameter changes from 20.0 cm to 6.00 cm in 0.50 s, what is the average induced current in milli-amps?
a circular loop of wire of cross-sectional area 0.12 m2 consists of 200 turns, each carrying...
a circular loop of wire of cross-sectional area 0.12 m2 consists of 200 turns, each carrying 0.50 A. It is placed in a magnetic field of 0.050 T oriented at 30> to the plane of the loop. What torque acts on the loop? how come it is Cos? and not sin . please show picture for explanation
A circular loop in the plane of a paper lies in a 0.65 T magnetic field...
A circular loop in the plane of a paper lies in a 0.65 T magnetic field pointing into the paper. The loop's diameter changes from 23.0 cm to 5.2 cm in 0.50 s . Part a) What is the direction of the induced current? Part b)What is the magnitude of the average induced emf? Part c) What is the average induced current if the coil resistance is 3.7 Ω ?
A circular loop in the plane of the paper lies in a 0.90 T magnetic field...
A circular loop in the plane of the paper lies in a 0.90 T magnetic field pointing into the paper. The resistance of the coil is 1.80 Ω. If the loop's diameter changes from 24.5 cm to 6.00 cm in 0.30 s, what is the average induced current in milli-amps? Answer in mA.
A circular loop in the plane of the paper lies in a 0.68 T magnetic field...
A circular loop in the plane of the paper lies in a 0.68 T magnetic field pointing into the paper. What is the magnitude of the average induced emf? If the coil resistance is 2.1 Ω , what is the average induced current?
A coil of wire with 4 loops, each having a cross sectional area of 11 cm^2...
A coil of wire with 4 loops, each having a cross sectional area of 11 cm^2 is in the uniform magnetic field of magnitude 4.8 x 10^-2T. The field is perpendicular to the plane of the loop in the coil. a. What is the magnetic flux through the loop in the coil? b. And if the magnitude of the field increase by a factor of 5.2, in a time of 3 seconds, what is the voltage induced in the coil?
A circular loop in the plane of the paper lies in a 0.90 T magnetic field...
A circular loop in the plane of the paper lies in a 0.90 T magnetic field pointing into the paper. The resistance of the coil is 1.80 Ω. If the loop's diameter changes from 21.5 cm to 9.00 cm in 0.45 s, what is the average induced current in milli-amps? incorrect answers - 13.635 mA and 35.13 mA
3. A circular loop in the plane of the paper lies in a 0.85 T magnetic...
3. A circular loop in the plane of the paper lies in a 0.85 T magnetic field pointing into the paper. The resistance of the coil is 2.20 2. If the loop's diameter changes from 22.5 cm to 900 cm in 0.30 s, what is the average induced current in milli-amps? XO MA Show my other submissions 6.16e-3
coil with 22 turns sits in a magnetic field. The cross-sectional area of the coil is...
coil with 22 turns sits in a magnetic field. The cross-sectional area of the coil is 9.6 cm2. If the magnetic field uniformly reduces from 11 T to 3.0 T in 6.0 seconds, what is the magnitude of the induced emf in that coil?
A square loop of wire of area A lies in the plane of the paper. The field changes at constant rate and after time T is directed out of the paper with the same magnitude it originally had inward. The magnitude of the change of flux through the coil in time T was (a) 2BA (b) BA (c) %BA (d) 4 BA (e) Zero
A coil of wire with 4 loops, each having a cross sectional area of 11 cm^2 is in the uniform magnetic field of magnitude 4.8 x 10^-2T. The field is perpendicular to the plane of the loop in the coil. a. What is the magnetic flux through the loop in the coil? b. And if the magnitude of the field increase by a factor of 5.2, in a time of 3 seconds, what is the voltage induced in the coil?
3. A circular loop in the plane of the paper lies in a 0.85 T magnetic field pointing into the paper. The resistance of the coil is 2.20 2. If the loop's diameter changes from 22.5 cm to 900 cm in 0.30 s, what is the average induced current in milli-amps? XO MA Show my other submissions 6.16e-3
