12. [1pt] White light passes from quartz to air, with an incident angle of 31.5°. Find...
12. [1pt]
White light passes from quartz to air, with an incident angle of
31.5°. Find the angle between the colours green (550 nm) and violet
(410 nm).
Correct, computer gets: 4.18e-01 deg
13. [1pt]
At what distance should you place a screen from the quartz surface
so that the two colours make brights spots that are 1.00 mm
apart?
Answer: Last
Answer: 0.173 mm
Incorrect, tries 9/15.
| Red | Orange | Yellow | Green | Blue | Violet | |
|---|---|---|---|---|---|---|
| 660 | 610 | 580 | 550 | 470 | 410 | |
| Water | 1.331 | 1.332 | 1.333 | 1.335 | 1.338 | 1.342 |
| Diamond | 2.410 | 2.415 | 2.417 | 2.426 | 2.444 | 2.458 |
| Crown glass | 1.512 | 1.514 | 1.518 | 1.519 | 1.524 | 1.530 |
| Flint glass | 1.662 | 1.665 | 1.667 | 1.674 | 1.684 | 1.698 |
| Polystyrene | 1.488 | 1.490 | 1.492 | 1.493 | 1.499 | 1.506 |
| Quartz | 1.455 | 1.456 | 1.458 | 1.459 | 1.462 | 1.468 |
Homework Answers
Add Answer to:
12. [1pt]
White light passes from quartz to air, with an incident angle of
31.5°. Find...
Problem 6: A narrow beam of light containing yellow (580 nm) and green (550 nm) wavelengths...
Problem 6: A narrow beam of light
containing yellow (580 nm) and green (550 nm) wavelengths goes from
polystyrene to air, striking the surface at a 25° incident angle
with respect to the normal.
Randomized Variables: Θ = 25
°
What is the angle in degrees between the colors when they emerge
from the polystyrene?
Θg - Θy =_______
Part (b) How far in meters would they have to
travel to be separated by 1.00 mm?
x=_________
Medium Red Orange Yellow...
(11%) Problem 9: Consider the index of refraction n in the selected media at various wavelengths...
(11%) Problem 9: Consider the index of refraction n in the selected media at various wavelengths as shown on the table. Medium Red Orange Yellow Green Blue Violet (660 nm) (610 nm) (580 nm) (550 nm) (470 nm) (410 nm) Water 1.331 1.332 | 1.333 1.335 1.338 | 1.342 Diamond 2.410 | 1.512 Glass, crown Glass, 1,662 flint Polystyrene 1.488 Quartz | 1.455 fused 2.415 2.4172.426 2.444 2.458 1.514 | 1.518 1.519 1.524 1.530 1,665 | 1667 1.674 1.684 1.698...
(11%) Problem 7: Consider a diamond surrounded by air. Glass, Red Orange Yellow Green Blue Violet...
(11%) Problem 7: Consider a diamond surrounded by air. Glass, Red Orange Yellow Green Blue Violet Medium m (660 nm) (610 nm) (580 nm) (550 nm) (470 nm) (410 nm) Water 1.331 1.332 | 1.333 1.335 1.338 1.342 Diamond 2.410 2.415 2.4172.426 2.444 2.458 1.512 1.514 1.518 1.519 1.524 1.530 1,662 1665 1.667 1.674 1.684 1698 flint Polystyrene 1,488 1.490 | 1.492 1.493 1.499 1.506 Quartz 1.455 1.456 | 1.458 1.459 1.462 | 1.468 fused Otheexpertta.com crown Glass, > A...
(11%) Problem 6: A beam of light containing orange (610 nm) and violet (410 nm) wavelengths...
(11%) Problem 6: A beam of light containing orange (610 nm) and violet (410 nm) wavelengths passes from fused quartz into water, striking the surface between them at a 49° incident angle with respect to the normal. Medium Red Orange Yellow Green Blue Violet (660 nm) (610 nm) (580 nm) (550 nm) (470 nm) (410 nm) | 1.331 1.332 1.333 | 1.335 | 1.338 1.342 Water Randomized Variables Diamond 2.410 2.415 2.4172.426 2.444 2.458 O= 49° Glass, | 1.512 1514...
Problem 5: Consider the index of refraction n in the selected media at various wavelengths as shown...
Problem 5: Consider the index of
refraction n in the selected media at various wavelengths
as shown on the table.
Part (a) What is the ratio of the speed of red
light to violet light in diamond?
Numeric : A numeric value is
expected and not an expression.
vR/vV =
__________________________________________
Part (b) What is this ratio in polystyrene?
Numeric : A numeric value is
expected and not an expression.
vR/vV =
__________________________________________
Problem 6: A narrow beam of light
containing yellow (580 nm)...
1. A beam of white light goes from air into water at an incident angle of...
1. A beam of white light goes from air into water at an incident angle of 67.0°. At what angles are the green (550 nm) and violet (410 nm) parts of the light refracted? (Enter your answer to at least one decimal place.) 2. The index of refraction for orange and violet light in diamond are respectively 2.415 and 2.458. The index of refraction for orange and violet light in fused quartz are respectively 1.456 and 1.468. Based on this...
Problem 6: A narrow beam of light
containing yellow (580 nm) and green (550 nm) wavelengths goes from
polystyrene to air, striking the surface at a 25° incident angle
with respect to the normal.
Randomized Variables: Θ = 25
°
What is the angle in degrees between the colors when they emerge
from the polystyrene?
Θg - Θy =_______
Part (b) How far in meters would they have to
travel to be separated by 1.00 mm?
x=_________
Medium Red Orange Yellow...
(11%) Problem 9: Consider the index of refraction n in the selected media at various wavelengths as shown on the table. Medium Red Orange Yellow Green Blue Violet (660 nm) (610 nm) (580 nm) (550 nm) (470 nm) (410 nm) Water 1.331 1.332 | 1.333 1.335 1.338 | 1.342 Diamond 2.410 | 1.512 Glass, crown Glass, 1,662 flint Polystyrene 1.488 Quartz | 1.455 fused 2.415 2.4172.426 2.444 2.458 1.514 | 1.518 1.519 1.524 1.530 1,665 | 1667 1.674 1.684 1.698...
(11%) Problem 7: Consider a diamond surrounded by air. Glass, Red Orange Yellow Green Blue Violet Medium m (660 nm) (610 nm) (580 nm) (550 nm) (470 nm) (410 nm) Water 1.331 1.332 | 1.333 1.335 1.338 1.342 Diamond 2.410 2.415 2.4172.426 2.444 2.458 1.512 1.514 1.518 1.519 1.524 1.530 1,662 1665 1.667 1.674 1.684 1698 flint Polystyrene 1,488 1.490 | 1.492 1.493 1.499 1.506 Quartz 1.455 1.456 | 1.458 1.459 1.462 | 1.468 fused Otheexpertta.com crown Glass, > A...
(11%) Problem 6: A beam of light containing orange (610 nm) and violet (410 nm) wavelengths passes from fused quartz into water, striking the surface between them at a 49° incident angle with respect to the normal. Medium Red Orange Yellow Green Blue Violet (660 nm) (610 nm) (580 nm) (550 nm) (470 nm) (410 nm) | 1.331 1.332 1.333 | 1.335 | 1.338 1.342 Water Randomized Variables Diamond 2.410 2.415 2.4172.426 2.444 2.458 O= 49° Glass, | 1.512 1514...
Problem 5: Consider the index of
refraction n in the selected media at various wavelengths
as shown on the table.
Part (a) What is the ratio of the speed of red
light to violet light in diamond?
Numeric : A numeric value is
expected and not an expression.
vR/vV =
__________________________________________
Part (b) What is this ratio in polystyrene?
Numeric : A numeric value is
expected and not an expression.
vR/vV =
__________________________________________
Problem 6: A narrow beam of light
containing yellow (580 nm)...
