For a 1-byte machine, convert the following numbers to binary (use 2's complement for negative numbers)...
For a 1-byte machine, convert the following numbers to binary (use 2's complement for negative numbers) then solve the equation. Comment on the result, if necessary. Write the final answer as a hex value.
a) 127 + 1
b) -1 - 5
c) -128 - 128
d) 0xA5 XOR 0xFF
Homework Answers
