Water in the bottom of a narrow metal tube is held at a constant temperature of...
Water in the bottom of a narrow metal tube is held at a constant temperature of 293.15 [K]. Water evaporates and diffuses through the air in the tube, and the diffusion path is 0.1524‐[m] long. The total pressure of air (assumed dry) is 101,325 [Pa] (1.0 [atm]) and the temperature is 293.15 [K] (20 [°C]). The diffusivity of water vapor in air at these conditions is 0.250×10–4 [m2/s]. Assume that the system is isothermal.
Requirements:
Calculate the evaporation flux at steady state.
Homework Answers
thankyou...please upvoye it...Add Answer to:
