A particle with charge q has an initial velocity Vx =300.0m/sx when it enters a region...
A particle with charge q has an initial velocity Vx =300.0m/sx when it enters a region of space with a uniform electric filed E=400.0V/my and a uniform magnetic field B=0.7Tz. The net force exerted on this particle is F=-0.0005Ny. Find the magnitude and sign of the charge q.
Homework Answers
so
charge will be negative and magnitude is 2.63uC.if you have any
questions please comment on this i resolve problem please rate this
question.
