A heat engine is proposed which is to operate between 2000 C and 500 C with...

A heat engine is proposed which is to operate between 2000 C and 500 C with a real efficiency of 35%.

(a) Convert the given temperatures to Kelvin

(b) Calculate the maximum efficiency(ideal efficiency) using the given temperatures

(c) Will the engine perform as predicted; that is will it have an efficiency of 35%? Explain.

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
A heat engine is proposed which is to operate between 2000 C and 500 C with...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • A proposed ocean thermal-energy conversion (OTEC) system is a heat engine that would operate between warm...

    A proposed ocean thermal-energy conversion (OTEC) system is a heat engine that would operate between warm water (15°C) at the ocean's surface and cooler water (3°C) 2,000 m below the surface. What is the maximum possible efficiency of the system? Enter your answer accurate to two decimal places.

  • A proposed ocean thermal-energy conversion (OTEC) system is a heat engine that would operate between warm...

    A proposed ocean thermal-energy conversion (OTEC) system is a heat engine that would operate between warm water (24°C) at the ocean's surface and cooler water (4°C) 1,711 m below the surface. What is the maximum possible efficiency of the system? Enter your answer accurate to two decimal places.

  • A plant (Heat Engine) has a boiler which provides heat at a temperature at 400 °C....

    A plant (Heat Engine) has a boiler which provides heat at a temperature at 400 °C. The plant rejects heat at a temperature of 100 °C. a) Sketch an ideal Carnot power cycle on a Temperature-Entropy diagram, label heat and work and show direction of cycle. b) What is the Carnot efficiency based on the given temperatures (Option 1). c) Calculate the efficiency for raising the heat by 50 °C (Option 2) and lowering the heat rejection by 50 °C...

  • ? Question 3: A heat engine is assumed to operate on a Carnot cycle. It receives...

    ? Question 3: A heat engine is assumed to operate on a Carnot cycle. It receives 600kJ heat from a high temperature reservoir at 600°C and rejects heat to a low temperature reservoir at 20°C. ooooo Calculate the thermal efficiency of the cycle. What is QL? What is the net work produced by this cycle? Does this process violate Kelvin-Plank statement? Explain. An inventor claimed that he built a heat engine operating between the same reservoirs that give a thermal...

  • a.) A particular car engine operates between temperatures of 400°C (inside the cylinders of the engine)...

    a.) A particular car engine operates between temperatures of 400°C (inside the cylinders of the engine) and 20°C (the temperature of the surroundings). Given these two temperatures, what is the maximum possible efficiency the car can have? (Note that actual car engine efficiencies are in the 20-25% range.) _______ % b.) A particular car engine operates between temperatures of 400°C (inside the cylinders of the engine) and 20°C (the temperature of the surroundings). If the car was somehow able to...

  • 5. A certain heat engine operates between 1000 K and 500 K a) What is the...

    5. A certain heat engine operates between 1000 K and 500 K a) What is the maximum efficiency of the engine? (ANS: 0.5) b) Calculate the maximum work that can be done per kJ of heat supplied by the hot source. (ANS: 0.5 kJ) c) How much heat is discharged into the cold sink in a reversible process for each kJ supplied by the hot source? (ANS: 0.25)

  • 7. We decide to store 200 MJ of electrical energy by driving a heat pump which...

    7. We decide to store 200 MJ of electrical energy by driving a heat pump which transfers heat from 20°C to molten salt at 500°C. This energy is retrieved later by running a heat engine between the same two temperatures. Both the heat pump and the engine can be described by efficiencies WIQH, and they both have the same ideal (Carnot) efficiency. A. What is the ideal efficiency of the heat pump? B. molten salt? Assuming ideal efficiency, how much...

  • A heat engine operates between a high temperature of about 600?C and a low temperature of...

    A heat engine operates between a high temperature of about 600?C and a low temperature of about 300?C. What is the maximum theoretical efficiency for this engine? A heat engine operates between a high temperature of about 600 and a low temperature of about 300. What is the maximum theoretical efficiency for this engine? A) =100%. B) ?66%. C) ?50%. D) ?34%. E) Cannot be determined from the given information.

  • 1) An ideal heat engine employing a carnot cycle Operates between two injerite heat reservoirs with...

    1) An ideal heat engine employing a carnot cycle Operates between two injerite heat reservoirs with the fixed temperatures To 7 To a) The heat engine has an efficiency n = 30% a work generator Find the efficiency of the machine y it is used as a refridgerator b) Braw the diagram of this cycle is T-S co-ords when used as

  • [3] A heat engine is reported to operate with 25 % efficiency when the cold reservoir...

    [3] A heat engine is reported to operate with 25 % efficiency when the cold reservoir is at 0° C. (a) Assuming this engine follows the Carnot cycle, what is the temperature of the hot reservoir? (b) Suppose the heat input to this engine was 10 J. Calculate the work done by this engine c) Suppose the heat input to this engine was 5). Calculate the heat rejected by this engine.
