A pipe with an internal diameter of 2.0 cm carries water to the basement of a...
A pipe with an internal diameter of 2.0 cm carries water to the basement of a house at a speed of 0.90 m / s with a pressure of 150 kPa. If the pipe narrows to 1.2 cm and rises to the second floor, 8.2 m above the point of entry, what is the water pressure on the second floor? (Consider acceleration of gravity equal to 10 m / s² and water density equal to 10³kg / m³)
| a. |
16,8 kPa |
|
| b. |
94,0 kPa |
|
| c. |
110,0 kPa |
|
| d. |
130,21 kPa |
|
| e. |
65,28 kPa |
Homework Answers
Add Answer to:
A pipe with an internal diameter of 2.0 cm carries water to the
basement of a...
Question 4 A water pipe having a 2.77 cm inside diameter cames water into the basement...
Question 4 A water pipe having a 2.77 cm inside diameter cames water into the basement of a house at a speed of 0.918 m/s and a pressure of 245 kPa. If the pipe tapers to 1.16 cm and rises to the second floor 6.24 m above the input point, what are the (a) speed and (b) water pressure at the second floor? (a) Number Units (b) Number Units Click if you would like to Show Work for this questions...
Please show your work and be clear a) speed vf ? b) water pressure pf at...
Please show your work and be clear
a) speed vf ?
b) water pressure pf at the second floor?
A water pipe having an inner diameter of di-250mc house at a speed v,- 0.90 m/s and a pressure pi -170k?a. cm carries water into the basement of:a 170 kPa. If the pipe tapers to a final inner diameter d, - 1.2 cm whi height 7.6 m above the input point, what are the: 1,000. kg/m' _12 cm while rising to...
A pump circulates water through a system of connected pipes on a house from the basement...
A pump circulates water through a system of connected pipes on a house from the basement to the top floor. The pump is located in the basement and drives water at 3.93m/s through a 6.99 cm diameter pipe at a gauge pressure of 425000 Pa. What will be the pressure (in kPa) in a 3.19 cm diameter pipe on the top floor, 21.6 m above the pipe? Please show work!
A 1.0-cm-diameter pipe widens to 2.0 cm, then narrows to 0.50 cm. Liquid flows through the...
A 1.0-cm-diameter pipe widens to 2.0 cm, then narrows to 0.50 cm. Liquid flows through the first segment at a speed of 4.0 m/s. What are the speeds in the second and third segments? What is the volume flow rate through the pipe? If all three parts of the pipe are at the same height and the pressure in the first segment is recorded at 80 kPa, what is the pressure in the second and third segments of the pipe?
In a section of horizontal pipe with a diameter of 4.0 cm, the pressure is 47...
In a section of horizontal pipe with a diameter of 4.0 cm, the pressure is 47 kPa and water is flowing with a speed of 2.0 m/s. The pipe narrows to 2.0 cm. What is the pressure in the narrower region? Treat the water as an ideal incompressible fluid. The density of water is 1000 kg/m3 . (1 kPa = 1000 Pa)
2 A pipe carrying water narrows 1 from a dizameter dy9.6 cm to a diameter d24.8...
2 A pipe carrying water narrows 1 from a dizameter dy9.6 cm to a diameter d24.8 cm as it: rises h1.0 m. Ai position 1 the gauge pressure is P1-1674 kPa and the speed is 2.8 m/s. Calculate the gauge pressure P2 at position 2 in units of kPa. Round your answer to the nearest whole number. Density of water is 1000 kg/m3.
A horizontal tube consists of a 7.0-cm diameter pipe that narrows to a 2.0-cm-diameter throat. In...
A horizontal tube consists of a 7.0-cm diameter pipe that narrows to a 2.0-cm-diameter throat. In the pipe, the water pressure is twice atmospheric pressure and the water flows with a speed of 0.40 ms. What is the pressure in the throat, assuming that the water behaves like an ideal fluid? The density of water is 1000 kg/m^3, and atmospheric pressure is 1.01 X 10^5Pa
A 7.5-cm-diameter horizontal pipe gradually narrows to 5.0 cm . When water flows through this pipe...
A 7.5-cm-diameter horizontal pipe gradually narrows to 5.0 cm . When water flows through this pipe at a certain rate, the gauge pressure in these two sections is 31.0 kPa and 25.0 kPa , respectively. What is the volume rate of flow? Q= ____ m^3/s Please explain step by step.
A 7.5-cm-diameter horizontal pipe gradually narrows to 5.0 cm . When water flows through this pipe...
A 7.5-cm-diameter horizontal pipe gradually narrows to 5.0 cm . When water flows through this pipe at a certain rate, the gauge pressure in these two sections is 31.0 kPa and 25.0 kPa , respectively. What is the volume rate of flow? Q= ____m^3/s
A 7.5-cm-diameter horizontal pipe gradually narrows to 5.0 cm . When water flows through this pipe...
A 7.5-cm-diameter horizontal pipe gradually narrows to 5.0 cm . When water flows through this pipe at a certain rate, the gauge pressure in these two sections is 31.0 kPa and 25.0 kPa , respectively. What is the volume rate of flow? Q= ____m^3/s I keep getting it wrong :(
Question 4 A water pipe having a 2.77 cm inside diameter cames water into the basement of a house at a speed of 0.918 m/s and a pressure of 245 kPa. If the pipe tapers to 1.16 cm and rises to the second floor 6.24 m above the input point, what are the (a) speed and (b) water pressure at the second floor? (a) Number Units (b) Number Units Click if you would like to Show Work for this questions...
Please show your work and be clear
a) speed vf ?
b) water pressure pf at the second floor?
A water pipe having an inner diameter of di-250mc house at a speed v,- 0.90 m/s and a pressure pi -170k?a. cm carries water into the basement of:a 170 kPa. If the pipe tapers to a final inner diameter d, - 1.2 cm whi height 7.6 m above the input point, what are the: 1,000. kg/m' _12 cm while rising to...
2 A pipe carrying water narrows 1 from a dizameter dy9.6 cm to a diameter d24.8 cm as it: rises h1.0 m. Ai position 1 the gauge pressure is P1-1674 kPa and the speed is 2.8 m/s. Calculate the gauge pressure P2 at position 2 in units of kPa. Round your answer to the nearest whole number. Density of water is 1000 kg/m3.
A horizontal tube consists of a 7.0-cm diameter pipe that narrows to a 2.0-cm-diameter throat. In the pipe, the water pressure is twice atmospheric pressure and the water flows with a speed of 0.40 ms. What is the pressure in the throat, assuming that the water behaves like an ideal fluid? The density of water is 1000 kg/m^3, and atmospheric pressure is 1.01 X 10^5Pa
