A piece of wire of length 20.0 m is tied horizontally between two posts. The speed...

A piece of wire of length 20.0 m is tied horizontally between two posts. The speed of a wave on this wire is 145 m/s. a) determine the fundamental frequency of standing waves set up on this wire b) determine the position of the 4th anti-node from the left end position (x=0) for a standing wave pattern on this wire that is associated with the 10th harmonic frequency. (use 4 sig figs while calculating)

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
A piece of wire of length 20.0 m is tied horizontally between two posts. The speed...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • A 1.5 m long string is tied between two posts. what is the wavelength of the...

    A 1.5 m long string is tied between two posts. what is the wavelength of the 2nd harmonic standing wave in the string? A/ 0.75m B/ 1.0m C/ 0.5 m D/ 1.5 m e/ 2.0 m

  • 4. A wire with mass density 1.00 g/m and length 1.80 m is stretched between two...

    4. A wire with mass density 1.00 g/m and length 1.80 m is stretched between two (fixed) clamps. It is vibrated at its third harmonic with a frequency of 240 Hz. a) Draw the standing wave pattern, labeling nodes and antinodes. b) What is the tension in the string? c) What is the fundamental frequency?

  • 6. A cord of ρ = 30 g/m is tightly tied between two strong posts a...

    6. A cord of ρ = 30 g/m is tightly tied between two strong posts a distance 3.0 m apart, so that it is under a tension of 100 N. The cord is plucked so that resonant standing waves are set up. (a) Find the three longest wavelengths that are allowed in the cord. (b) Find the corresponding frequencies. (c) The tension is now adjusted so that the new fundamental frequency corresponds to that of the second overtone in part...

  • A steel wire having a mass of 6.30 g and a length of 1.20 m is...

    A steel wire having a mass of 6.30 g and a length of 1.20 m is fixed at both ends and has a tension of 955 N. (a) Find the speed of transverse waves on the wire. 1 405 Incorrect: Your answer is incorrect. m/s (b) Find the wavelength of the fundamental. 2 m (c) Find the frequency of the fundamental. 3 Hz (d) Find the frequency of the second harmonic. 4 Hz (e) Find the frequency of the third...

  • Two wires, each of length 1.2 m, are stretched between two fixed supports. On wire A...

    Two wires, each of length 1.2 m, are stretched between two fixed supports. On wire A there is a second-harmonic standing wave whose frequency is 731 Hz. However, the same frequency of 731 Hz is the third harmonic on wire B. Find the speed at which the individual waves travel on each wire.

  • Two wires, each of length 1.9 m, are stretched between two fixed supports. On wire A...

    Two wires, each of length 1.9 m, are stretched between two fixed supports. On wire A there is a second-harmonic standing wave whose frequency is 635 Hz. However, the same frequency of 635 Hz is the third harmonic on wire B. Find the speed at which the individual waves travel on each wire.

  • A 53-m length of wire is stretched horizontally between two vertical posts. The wire carries a...

    A 53-m length of wire is stretched horizontally between two vertical posts. The wire carries a current of 68 A and experiences a magnetic force of 0.16 N. Find the magnitude of the earth's magnetic field at the location of the wire, assuming the field makes an angle of 75.0° with respect to the wire.

  • A 59-m length of wire is stretched horizontally between two vertical posts. The wire carries a...

    A 59-m length of wire is stretched horizontally between two vertical posts. The wire carries a current of 78 A and experiences a magnetic force of 0.18 N. Find the magnitude of the earth's magnetic field at the location of the wire, assuming the field makes an angle of 64.0 degree with respect to the wire.

  • Q. A steel wire with mass 37.0 g and length 7.10 m is stretched tightly between...

    Q. A steel wire with mass 37.0 g and length 7.10 m is stretched tightly between its two endpoints. In its fundamental mode, the wire vibrates at a frequency of 59.0 Hz. When plucked, traveling waves bounce from one end to the other. a) What is the speed of waves propagating along the wire? b) Calculate the tension in the wire. c) A standing wave at the fundamental frequency has an amplitude of 0.340 cm . Calculate the magnitude of...

  • A 45-m length of wire is stretched horizontally between twovertical posts. The wire carries a current...

    A 45-m length of wire is stretched horizontally between twovertical posts. The wire carries a current of 76 A and experiences a magnetic force of 0.15 N. Findthe magnitude of the earth's magnetic field at the location of thewire, assuming the field makes an angle of 55.5° with respect to the wire.
