A clarinet has a lowest pitch note (i.e. lowest resonant frequency) of 147 Hz under normal conditions.

a) What is the wavelength of this resonance?
b) If the clarinet is like a tube with one open end and one closed end, how long must that tube be? Compare this calculation to the length of an actual clarinet, approximately 60 cm.

science physics

Answer 1

Answer #1

Answer 2
