Charge q1 = 25nC is at the origin and charge q2 = -15nC is on the...

Question

Question

Charge q1 = 25nC is at the origin and charge q2 = -15nC is on the...

Charge q1 = 25nC is at the origin and charge q2 = -15nC is on the x-axis at x=2m

Find the magnitude and direction of the resultant electric field at the point x = 1m and y = 2m

science physics

Add a comment Improve this question Transcribed image text

Answer 1

Answer #1

Add a comment

Answer 2
