A simple harmonic wave in a cable is traveling in the x direction with velocity 235...

Question

Question

A simple harmonic wave in a cable is traveling in the x direction with velocity 235 m/s. The wavelength is 1.55m.

a. What is the frequency of the wave?

b. What is the period of the wave?

c. If the tension in the cable is 7.50 ∗ 104 ?, what is the mass density of the cable?

science physics

Answer 1

Answer #1

Answer 2
