Two long, parallel wires are separated by a distance of 4.00 cm . The force per...
|
Two long, parallel wires are separated by a distance of 4.00 cm . The force per unit length that each wire exerts on the other is 4.80×10−5 N/m , and the wires repel each other. The current in one wire is 0.700 A . |
Part A What is the current in the second wire?
SubmitRequest Answer Part B Are the two currents in the same direction or in opposite directions? Are the two currents in the same direction or in opposite directions?
|
