Magnetic resonance imaging (MRI) scans are often prohibited for patients with an implanted device, such as...

Magnetic resonance imaging (MRI) scans are often prohibited for patients with an implanted device, such as a pacemaker. There are multiple reasons for this prohibition. One reason is the physical torque on the device due to the MRI's magnetic field. Suppose a patient’s pacemaker implant requires ?=1.6 mA of current to function. The leads of the device travel close together until they reach the heart and then split off to touch the top and bottom of the heart, such that size of the current loop is approximately half the cross-sectional area of the heart. Suppose the MRI machine uses a magnetic field of ?=2.4 T. Treating the heart as a box that is ?=14.0 cm long and ?=8.0 cm wide, calculate the magnitude of the maximum torque ? on the current loop.

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
Magnetic resonance imaging (MRI) scans are often prohibited for patients with an implanted device, such as...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • treating the heart as a box that is L = 13.0 cm long and W =...

    treating the heart as a box that is L = 13.0 cm long and W = 10.0 cm wide, calculate the magnitude of the maximum torque on the current loop. suppose a patients pacemaker implants requires I = 1.8 mA of current to function. the leads of the device travel close together until they reach the heart and then split off to touch the top and bottom of the heart, such that size of the current loop is approximately half...

  • A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove...

    A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove a 8.1 cm diameter metallic bracelet. The resistance of the bracelet is 0.0110 Ω. The magnetic field within the MRI's solenoid is perpendicular to the opening of her bracelet. While taking the scan, the magnetic field decreases from 1.05 T to 0.35 T in 1.50 seconds. What is the magnitude of the average induced voltage in the bracelet?

  • A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove...

    A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove a 7.7 cm diameter metallic bracelet. The resistance of the bracelet is 0.00900 Ω. The magnetic field within the MRI's solenoid is perpendicular to the opening of her bracelet. While taking the scan, the magnetic field decreases from 1.03 T to 0.43 T in 0.900 seconds. What is the magnitude of the average induced voltage in the bracelet?

  • A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove...

    A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove a 7.7 cm diameter metallic bracelet. The resistance of the bracelet is 0.00900 Ω. The magnetic field within the MRI's solenoid is perpendicular to the opening of her bracelet. While taking the scan, the magnetic field decreases from 1.03 T to 0.43 T in 0.900 seconds. What is the magnitude of the average induced voltage in the bracelet?

  • A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove...

    A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove a 6.5 cm diameter metallic bracelet. The resistance of the bracelet is 0.00900 Ω. The magnetic field within the MRI's solenoid is perpendicular to the opening of her bracelet. While taking the scan, the magnetic field decreases from 1.35 T to 0.39 T in 1.50 seconds. What is the magnitude of the average induced voltage in the bracelet?

  • A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove...

    A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove a 8.9 cm diameter metallic bracelet. The resistance of the bracelet is 0.00900 Ω. The magnetic field within the MRI's solenoid is perpendicular to the opening of his bracelet. While taking the scan, the magnetic field decreases from 1.06 T to 0.41 T in 1.10 seconds. What is the magnitude of the average induced voltage in the bracelet?

  • A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove...

    A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove a 6.5 cm diameter metallic bracelet. The resistance of the bracelet is 0.0170 Ω. The magnetic field within the MRI's solenoid is perpendicular to the opening of his bracelet. While taking the scan, the magnetic field decreases from 1.35 T to 0.43 T in 1.30 seconds. What is the magnitude of the average induced voltage in the bracelet?

  • A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove...

    A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove a 6.9 cm diameter metallic bracelet. The resistance of the bracelet is 0.0150 Ω. The magnetic field within the MRI's solenoid is perpendicular to the opening of his bracelet. While taking the scan, the magnetic field decreases from 1.43 T to 0.51 T in 1.10 seconds. What is the magnitude of the average induced voltage in the bracelet? (Answer in Volts)

  • A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove...

    A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove a 8.7 cm diameter metallic bracelet. The resistance of the bracelet is 0.0150 2. The magnetic field within the MRI'S solenoid is perpendicular to the opening of her bracelet. While taking the scan, the magnetic field decreases from 1.2 T to d.43 T in 1.30 seconds. What is the magnitude of the average induced voltage in the bracelet? Tries 0/20 Submit Answer

  • A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove...

    A patient is having a magnetic resonance imaging scan (an MRI) and has neglected to remove a 8.9 cm diameter metallic bracelet. The resistance of the bracelet is 0.0110 2. The magnetic field within the MRI's solenoid is perpendicular to the opening of her bracelet. While taking the scan, the magnetic field decreases from 1.04 T to 0.35 T in 1.50 seconds. What is the magnitude of the average induced voltage in the bracelet? Tries 0/20. Submit Ancwor.
