a 150 g hamster sitting on an 840 g wedge-shaped block. The block, in turn, rests...
a 150 g hamster sitting on an 840 g wedge-shaped block. The block, in turn, rests on a spring scale.
a) If the hamster is able to grip the surface of the block so that he doesn't slide, then what is the reading on the spring scale?
b) For the situation as described in Part A, what is the magnitude of the force on the hamster by the block?
c) Suppose that, instead of the situation described in Part A, the block has a frictionless upper surface, so that the hamster will slide down. However, there is significant friction between the lower surface of the block and the surface of the spring scale (and between the scale and the floor), so that the block never slips on the scale. While the hamster is sliding down, what is the magnitude of the force on the hamster by the block?
d) For the situation described in Part C, what does the scale read as the hamster slides down?
Explain why as well please.
Homework Answers
Add Answer to:
a 150 g hamster sitting on an 840 g wedge-shaped block. The
block, in turn, rests...
(Figure 1)shows a 250 g hamster sitting on an 750 g wedge-shaped block. The block, in...
(Figure 1)shows a 250 g hamster sitting on an 750 g wedge-shaped
block. The block, in turn, rests on a spring scale. An extra-fine
lubricating oil having μs=μk=0 is sprayed on the top surface of the
block, causing the hamster to slide down. Friction between the
block and the scale is large enough that the block does
not slip on the scale.
1. What does the scale read, in grams, as the hamster slides
down? Express your answer with the...
I don't even know where to start for this problem! help please!
A 200g hamster is sitting on a 800g wedge-shaped block. The block, in turn, rests on a spring scale.a) Initially, static friction is sufficient to keep the hamster from moving. In this case, the hamster and the block are effectively a single 1000g mass and the scaleshould read 9.8N. Show that this is the case by treating the hamster and the block as separate objects and analyzing forces.b) An extra fine lubricating oil having µs= µk= 0 is sprayed on...
The figure above shows an object (blue) on top of a wedge (gray) sitting on a...
The figure above shows an object (blue) on top of a wedge (gray)
sitting on a scale (black). When the object is released, is slides
down the slope of the wedge. What is the normal force of the scale
on the wedge (this is the force the scale will read) as the mass
slides down the slope?
There is friction between the object and the wedge and between
the wedge and the scale. The static friction between the wedge and...
A block of mass 20kg rests on a wedge (θ=30∘) as shown in the figure below....
A block of mass 20kg rests on a wedge (θ=30∘) as shown in the figure below. The two objects move to the right in such a way that the block doesn't slide up or down the wedge. The coefficient of static friction between the block and the wedge is 0.35. what is the minimum and maximum acceleration of the two objects?
A 14 kg block on a horizontal surface is attached to a horizontal spring of spring...
A 14 kg block on a horizontal surface is attached to a horizontal spring of spring constant k = 5.7 kN/m. The block is pulled to the right so that the spring is stretched 15 cm beyond its relaxed length, and the block is then released from rest. The frictional force between the sliding block and the surface has a magnitude of 44 N. (a) What is the kinetic energy of the block when it has moved 3.0 cm from...
Awerte with mass rests on a frictionless horizontal tabletop A block with mass mis placed on...
Awerte with mass rests on a frictionless horizontal tabletop A block with mass mis placed on the wedge and a horizontal force is applied to the wedge. There M is no friction between the block and the weige For a = */6 what must the magnitude of F be if the block is to remain at a constant height above the tabletop? (o is the magnitude of the gravitational acceleration Take m = 1 kg = 5 kg and g...
Problem 1 (10 points) Block A, with weight 3w, slides down an inclined plane S of...
Problem 1 (10 points) Block A, with weight 3w, slides down an inclined plane S of slope angle 36.9 at a constant speed while plank B, with weight w, rests on top of A. The plank is attached by a cord to the wall as shown below. (a) Draw a free body diagram for block A. (b) Draw a free body diagram for plank B. (c) If the coefficient of kinetic friction is the same between A and B and...
A small block (m1 = 4.0 kg) rests on an inclined plane (m2 = 12.0 kg,...
A small block (m1 = 4.0 kg) rests on an inclined plane (m2 = 12.0 kg, ? = 53.13?). The coeffi- cients of static and kinetic friction between the surfaces of the block and the ramp are, respectively, ?s = 0.333 and ?k = 0.200. A force F?P pushes horizontally on the inclined plane to the right, causing the system to accelerate. If the force F?P is too large, the small block will slide up the ramp, whereas, if the...
A block with mass M rests on a frictionless surface and is connected to a horizontal spring of force constant k. The oth...
A block with mass M rests on a frictionless surface and is connected to a horizontal spring of force constant k. The other end of the spring is attached to a wall. A second block with mass m rests on top of the first block. The coefficient of static friction between the a blocks is μs. a) Find the maximum amplitude of oscillation such that the top block will not slip on the bottom block. b) Suppose the coefficient of...
A solid block of mass 60.0 kg starts from rest and slides down a rough surface...
A solid block of mass 60.0 kg starts from rest and slides down a rough surface with a length of 10.0 m where the coefficient of friction is uk=0.20. The surface is inclined at 40.0°. After sliding 10 meters down the incline it hits a spring with a spring constant of ks = 550.0 N/m. Draw a freebody Diagram indicating all forces. Write out and solve the force and energy equations. How high is the block above the spring at...
(Figure 1)shows a 250 g hamster sitting on an 750 g wedge-shaped
block. The block, in turn, rests on a spring scale. An extra-fine
lubricating oil having μs=μk=0 is sprayed on the top surface of the
block, causing the hamster to slide down. Friction between the
block and the scale is large enough that the block does
not slip on the scale.
1. What does the scale read, in grams, as the hamster slides
down? Express your answer with the...
The figure above shows an object (blue) on top of a wedge (gray)
sitting on a scale (black). When the object is released, is slides
down the slope of the wedge. What is the normal force of the scale
on the wedge (this is the force the scale will read) as the mass
slides down the slope?
There is friction between the object and the wedge and between
the wedge and the scale. The static friction between the wedge and...
Awerte with mass rests on a frictionless horizontal tabletop A block with mass mis placed on the wedge and a horizontal force is applied to the wedge. There M is no friction between the block and the weige For a = */6 what must the magnitude of F be if the block is to remain at a constant height above the tabletop? (o is the magnitude of the gravitational acceleration Take m = 1 kg = 5 kg and g...
Problem 1 (10 points) Block A, with weight 3w, slides down an inclined plane S of slope angle 36.9 at a constant speed while plank B, with weight w, rests on top of A. The plank is attached by a cord to the wall as shown below. (a) Draw a free body diagram for block A. (b) Draw a free body diagram for plank B. (c) If the coefficient of kinetic friction is the same between A and B and...
A solid block of mass 60.0 kg starts from rest and slides down a rough surface with a length of 10.0 m where the coefficient of friction is uk=0.20. The surface is inclined at 40.0°. After sliding 10 meters down the incline it hits a spring with a spring constant of ks = 550.0 N/m. Draw a freebody Diagram indicating all forces. Write out and solve the force and energy equations. How high is the block above the spring at...
