This problem is good for getting some feel for thermodynamic quantities. For each of the following...
This problem is good for getting some feel for thermodynamic quantities. For each of the following processes deduce whether each of the quantities Q, W (PdV work), Delta U, Delta H, Delta S, and Delta T are positive, negative, or zero. The system is the substance mentioned in the problem.
e) Reversible heating of liquid water (from 20 to 50 C) at constant P.
f) Reversible cooling of steam at constant V.
g) Reversible freezing of liquid water at 101.33kPa (1 atm) and 0 C.
h) Reversible boiling (vaporizing) of water at 101.33 kPa and 100 C.
Homework Answers
