A generator has 100 turns of wire with an area of 0.090m2 and total resistance of...
A generator has 100 turns of wire with an area of
0.090m2 and total resistance of
12 ohms. It rotates in a field B=
0.50T with 60 revolutions/seconds.
Calculate the maximum emf.
Im sorry i submitted the wrong picture. I will submitt the actual cuestion in english in a sec.
Homework Answers
