1.) A lens is constructed using glass for which the index of refraction is 1.50 and...

1.) A lens is constructed using glass for which the index of refraction is 1.50 and when placed in air it has a focal length of 48 mm. Suppose the lens is placed in water. Does the focal length remain the same or change? If it changes, describe whether it is larger than or smaller than 48 mm. Explain your answer.

2.) A projector uses a convex lens to form an image of an object that is 4.0 cm tall. The image is 1.2 m tall. The distance from the lens of the screen is 3.0 m. Determine the focal length of the lens needed to do this.
science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
1.) A lens is constructed using glass for which the index of refraction is 1.50 and...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • A thin lens is made of material that has an index of refraction of 1.50. When...

    A thin lens is made of material that has an index of refraction of 1.50. When an object 10 mm tall is placed 500 mm away from the lens, an upright image 31.5 mm tall is formed. One surface of the lens is concave, with an absolute value of radius of curvature of 350 mm. What is the radius of curvature of the other surface? Express your answer with the appropriate units. Follow the sign convention

  • A lens is made from glass with an index of refraction of 1.66 for violet light...

    A lens is made from glass with an index of refraction of 1.66 for violet light and 1.61 for red light. Both sides of the lens are convex with equal radii of curvature. For which color, violet or red, is the focal length larger? Explain how you know.

  • A typical human lens has an index of refraction of 1.430. The lens has a double...

    A typical human lens has an index of refraction of 1.430. The lens has a double convex shape, but its curvature can be varied by the ciliary muscles acting around its rim. At minimum power, the radius of the front of the lens is 10.0 mm, whereas that of the back is 6.00 mm. At maximum power, the radii are 6.50 mm and 5.50 mm, respectively. If the lens were in air, what would be the maximum power and associated...

  • A lens produces a real image of a real object. a) Is the image inverted or upright? b) Is the lens diverging or conver...

    A lens produces a real image of a real object. a) Is the image inverted or upright? b) Is the lens diverging or converging? c) Is the image enlarged or reduced in size? d) If two convex lenses identical in size and shape aremanufactured from glass with two different indices of refraction,would the focal length of the lens with the greater index ofrefraction (lens 1) be larger or smaller than that of the otherlens (lens 2)?

  • A candle name 9.10 cm from a lens produces a real image 13.30 cm from the...

    A candle name 9.10 cm from a lens produces a real image 13.30 cm from the lens. The lens has one flat side and one curved side, is made of glass with an index of refraction of 1.52, and is surrounded by air, (a) Calculate the focal length of the lens. Be sure to include the appropriate sign and units. (b) Calculate the radius of curvature of the curved side of the lens. (c) Is the curved side convex or...

  • The thick lens shown at right is made from glass with index of refraction 1.50. The...

    The thick lens shown at right is made from glass with index of refraction 1.50. The thick lens has thickness of 6.0 cm and radii of curvature of 8.00 cm and 10.00 cm. (a) Find the focal length of this thick lens in air and the position of its focal points (F and F) and its principal points (H, and H,) with respect to the front and back of the lens respectively. (b) Draw a sketch showing the locations of...

  • A typical human lens has an index of refraction of 1.430. The lens has a double...

    A typical human lens has an index of refraction of 1.430. The lens has a double convex shape, but its curvature can be varied by the ciliary muscles acting around its rim. At minimum power, the radius of the front of the lens is 10.0 mm, whereas that of the back is 6.00 mm. At maximum power, the radii are 6.50mm and 5.5mm, respectively. If the lens were in air: What would be the maximum power and associated focal length...

  • A certain thin lens is made of glass with refraction index ?lens=1.500. In air, where the...

    A certain thin lens is made of glass with refraction index ?lens=1.500. In air, where the index of refraction is 1.000, the lens has focal length ?0=15.5 cm. What is the focal length ? of the lens when immersed in water, where the index of refraction is 1.330?

  • A certain thin lens is made of glass with refraction index nlens = 1.500. In air,...

    A certain thin lens is made of glass with refraction index nlens = 1.500. In air, where the index of refraction is 1.000, the lens has focal length f0 = 26.5 cm. What is the focal length f of the lens when immersed in oil, where the index of refraction is 1.460?

  • A lens made from glass with an index of refraction of 1.66 had two convex surfaces, one with a ra...

    A lens made from glass with an index of refraction of 1.66 had two convex surfaces, one with a radius of 30 cm and the other with a radius of 50 cm. What is the focal length of the lens if it is surrounded by air?
