UNO digital pins 0 to 7 are connected to Port D of the ATmega328 microcontroller while...
UNO digital pins 0 to 7 are connected to Port D of the ATmega328 microcontroller while digital pins 8 to 13 are to Port B. Without using pinMode( ), write down as few Cstatements as possible on DDRB/DDRD/PORTB/PORTD to achieve the configuration of:
digital pins 2, 4, and 5 as OUPUT pins,
digital pins 7 and 8 as INPUT pins,
digital pins 3 and 11 as INPUT_PULLUP pins, and
all the other digital pins should not be changed.
Homework Answers
Add Answer to:
UNO digital pins 0 to 7 are connected to Port D of the ATmega328
microcontroller while...
