A uniform thin rod of mass M=3.15 kg pivots about an axis through its center and...

A uniform thin rod of mass M=3.15 kg pivots about an axis through its center and perpendicular to its length. Two small bodies, each of mass m=0.235 kg, are attached to the ends of the rod. What must the length L of the rod be so that the moment of inertia of the three-body system with respect to the described axis is I=0.995 kg·m2 ?

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
A uniform thin rod of mass M=3.15 kg pivots about an axis through its center and...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • A uniform thin rod of mass M- 4.27 kg pivots about an axis through its center...

    A uniform thin rod of mass M- 4.27 kg pivots about an axis through its center and perpendicular to its L of the rod be so that the moment of inertia of the three-body system with respect to the described axis is I -0.983 kg m2? Number rm H7I 7i

  • A very thin, straight, uniform rod has a length of 3.00 m and a total mass...

    A very thin, straight, uniform rod has a length of 3.00 m and a total mass of 7.00 kg. Treating the rod as essentially a line segment of mass (distributed uniformly), do the following: (i) Use integration to prove that the rod's center of mass is located at its center point. (Reminders: dmnds mass (and that axis is perpendicular to the rod). with the previous result-to calculate lemr the moment of inertia of the rod about an axis through one...

  • A thin uniform rod (length = 1.77 m, mass = 3.13 kg) is pivoted about a...

    A thin uniform rod (length = 1.77 m, mass = 3.13 kg) is pivoted about a horizontal frictionless pin through one of its ends. The moment of inertia of the rod through this axis is (1/3)mL2. The rod is released when it is 58.5° below the horizontal. What is the angular acceleration of the rod at the instant it is released? (in rad/s^2) A: 2.712 B: 3.173 C: 3.713 D: 4.344 E: 5.082 F: 5.946 G: 6.957 H: 8.140

  • A uniform rod of mass 2.00 kg and length 2.00 m is capable of rotating about...

    A uniform rod of mass 2.00 kg and length 2.00 m is capable of rotating about and passing through its center and perpendicular to its length. A mass m, m, 2.70 kg is attached to the other end of the red treat the two massess point partides. 5.50 kg is attached to one end and a seconds (a) What is the moment of inertia of the system in kg.my (6) If the rod rotates with an angular speed of 2.60...

  • (a) Knowing that the moment of inertia of a thin uniform metallic rod of mass m...

    (a) Knowing that the moment of inertia of a thin uniform metallic rod of mass m and length L about an axis through its center of mass is (1/12) ml?, what is its moment of inertial about a parallel axis through one of its ends (show your calculation). (b) A physical pendulum consisting of a thin metallic rod of mass m = 200.0 g and of length L = 1.000 m is suspended from the upper end by a frictionless...

  • 1. a. A very thin, straight, uniform rod has a length of 3.00 m and a...

    1. a. A very thin, straight, uniform rod has a length of 3.00 m and a total mass of 700 kg. Treating the rod as essentially a line segment of mass (distributed uniformly), do the following: (i) Use integration to prove that the rod's center of mass is located at its center point. ii) Now use integration to calculatethe moment of inertia of the rod about an axis through that center of (ii) Now use two different methods-first by direct...

  • A thin rod has a length of 0.834 m and rotates in a circle on a...

    A thin rod has a length of 0.834 m and rotates in a circle on a frictionless tabletop. The axis is perpendicular to the length of the rod at one of its ends. The rod has an angular velocity of 0.610 rad/s and a moment of inertia of 1.42 x 10-3 kg·m2. A bug standing on the axis decides to crawl out to the other end of the rod. When the bug (whose mass is 5 x 10-3 kg) gets...

  • A thin rod has a length of 0.266 m and rotates in a circle on a...

    A thin rod has a length of 0.266 m and rotates in a circle on a frictionless tabletop. The axis is perpendicular to the length of the rod at one of its ends. The rod has an angular velocity of 0.796 rad/s and a moment of inertia of 1.19 x 10-3 kg·m2. A bug standing on the axis decides to crawl out to the other end of the rod. When the bug (whose mass is 5 x 10-3 kg) gets...

  • A thin rod has a length of 0.109 m and rotates in a circle on a...

    A thin rod has a length of 0.109 m and rotates in a circle on a frictionless tabletop. The axis is perpendicular to the length of the rod at one of its ends. The rod has an angular velocity of 0.923 rad/s and a moment of inertia of 1.40 x 10-3 kg·m2. A bug standing on the axis decides to crawl out to the other end of the rod. When the bug (whose mass is 5 x 10-3 kg) gets...

  • An object is formed by attaching a uniform, thin rod with a mass of mr =...

    An object is formed by attaching a uniform, thin rod with a mass of mr = 7.31 kg and length L = 5.68 m to a uniform sphere with mass ms = 36.55 kg and radius R = 1.42 m. Note ms = 5mr and L = 4R. *What is the moment of inertia of the object about an axis at the left end of the rod? *If the object is fixed at the left end of the rod, what...
