Part A What is the magnitude of the force per meter of length on a straight wire carrying an 7.50-A current when perpendicular to a 0.55-T uniform magnetic field?

Express your answer to two significant figures and include the appropriate units.

ANSWER: Fl =

Part B What if the angle between the wire and field is 53.0 ∘?

Express your answer to two significant figures and include the appropriate units.

ANSWER: Fl = ?

science physics

Add a comment Improve this question Transcribed image text

Answer 1

Answer #1

Add a comment
