Copper is to be deposited from a solution that is 0.200 M in Cu(II) and is...
- Copper is to be deposited from a solution that is 0.200 M in Cu(II) and is buffered to a pH of 4.00. Oxygen is evolved from the anode at a partial pressure of 0.974 atm. The cell has a resistance of 3.60 Ω. The temperature is 25 oC.
Cu2+ + 2e- = Cu(s) Eo = .339V
½ O2 + 2H+ + 2e- = H2O Eo = 1.229V
Calculate:
- the theoretical potential, Ecell, needed to initiate deposition of copper from this solution.
- the IR drop associated with a current of 0.10 A in this cell.
- the initial potential, given that the overvoltage of oxygen is 0.50 V under these conditions.
- the potential of the cell when [Cu2+] is 8.00 x 10-6M, assuming that IR drop and O2 overvoltage remain unchanged.
Homework Answers
if you have any doubts comment
belowAdd Answer to:
