Suppose that a single long wire carried a current of 100 A. At a distance of...

Question

Question

Suppose that a single long wire carried a current of 100 A. At a distance of 2 cm from the wire, what would be its magnetic field?

a. 1 T

b. .1 T

c. .01 T

d. 0.001 T

science physics

Answer 1

Answer #1

Answer 2
