m A circular coil (950 turns, radius 5 0.060 m) is rotating in a uni- form...
m A circular coil (950 turns, radius 5 0.060 m) is rotating in a uni- form magnetic field. At t 5 0 s, the normal to the coil is perpendicular to the magnetic field. At t 5 0.010 s, the normal makes an angle of f 5 45° with the field because the coil has made one-eighth of a revolution. An average emf of magnitude 0.065 V is induced in the coil. Find the magni- tude of the magnetic field at the location of the coil.
Homework Answers
Add Answer to:
m A circular coil (950 turns, radius 5 0.060 m) is rotating in a
uni- form...
A circular coil (800 turns, radius = 0.040 m) is rotating in a uniform magnetic field....
A circular coil (800 turns, radius = 0.040 m) is rotating in a uniform magnetic field. At t = 0 s, the normal to the coil is perpendicular to the magnetic field. At t = 0.028 s, the normal makes an angle of 45o with the field because the coil has made one-eighth of a revolution. An average emf of magnitude 0.094 V is induced in the coil. Find the magnitude of the magnetic field at the location of the...
A circular coil (650 turns, radius = 0.076 m) is rotating in a uniform magnetic field....
A circular coil (650 turns, radius = 0.076 m) is rotating in a uniform magnetic field. At t = 0 s, the normal to the coil is perpendicular to the magnetic field. At t = 0.012 s, the normal makes an angle of 45o with the field because the coil has made one-eighth of a revolution. An average emf of magnitude 0.098 V is induced in the coil. Find the magnitude of the magnetic field at the location of the...
A circular coil of wire with radius 2 cm and 60 turns is placed in a...
A circular coil of wire with radius 2 cm and 60 turns is placed in a uniform magnetic field of magnitude 0.8 T. The magnetic field is parallel to the area vector; i.e. perpendicular to the plane of the coil. a) What is the magnetic flux through the coil? b) The magnetic field is decreased to 0 T in 0.1 s. What is the magnitude of the emf induced in the coil during this time interval? c) If the coil...
A circular coil of wire with radius 4 cm and 20 turns is placed in a...
A circular coil of wire with radius 4 cm and 20 turns is placed in a uniform magnetic field of magnitude 0.3 T. The magnetic field is parallel to the area vector; i.e. perpendicular to the plane of the coil. a) What is the magnetic flux through the coil? b) The magnetic field is decreased to 0 T in 0.1 s. What is the magnitude of the emf induced in the coil during this time interval? c) If the coil...
A circular coil that has N = 210 turns and a radius of r = 9.00...
A circular coil that has N = 210 turns and a radius of r = 9.00 сm lies in a magnetic field that has a magnitude of Bo = 0.0600 T directed perpendicular to the plane of the coil. What is the magnitude of the magnetic flux Og through the coil? OB = 0.321 The magnetic field through the coil is increased steadily to 0.180 T over a time interval of 0.515 s. What is the magnitude El of the...
A circular coil that has 120 turns and a radius of 10.0 cm lies in a...
A circular coil that has 120 turns and a radius of 10.0 cm lies in a magnetic field that has a magnitude of 0.0650 T directed perpendicular to the coil. What is the magnetic flux through the coil? (Express your answer to three significant figures.) The magnetic field through the coil is increased steadily to 0.100 T over a time interval of 0.300 s. What is the magnitude of the emf induced in the coil during the time interval? (Express...
1. (20 pts) A circular coil with a radius of 8.0 cm is dropped from a...
1. (20 pts) A circular coil with a radius of 8.0 cm is dropped from a location where the magnetic field is 0.2 T into a region where the magnetic field is 1.6 T. The coil takes 0.12 s to fall, has 60 turns and is perpendicular to the magnetic field. The field does not change direction. a. Find the average induced emf in the coil as a result of this action. b. If the induced current flows clockwise as...
A circular coil that has N 280 turns and a radius of r 9.50 cm lies...
A circular coil that has N 280 turns and a radius of r 9.50 cm lies in a magnetic field that has a magnitude of Bo 0.0635 T directed perpendicular to the plane of the coil. what is the magnitude of the magnetic flux Φ B through the coil? T-m2 The magnetic field through the coil is increased steadily to 0.145 T over a time interval of 0.305 s. What is the magnitude |El of the emf induced in the...
A flat circular coil with 167 turns, a radius of 5.73 x 10-2 m, and a...
A flat circular coil with 167 turns, a radius of 5.73 x 10-2 m, and a resistance of 0.228 2 is exposed to an external magnetic field that is directed perpendicular to the plane of the coil. The magnitude of the external magnetic field is changing at a rate of AB/At = 0.628 T/s, thereby inducing a current in the coil. Find the magnitude of the magnetic field at the center of the coil that is produced by the induced...
A flat circular coil with 178 turns, a radius of 4.94 x 10-2 m, and a...
A flat circular coil with 178 turns, a radius of 4.94 x 10-2 m, and a resistance of 0.303 Ω is exposed to an external magnetic field that is directed perpendicular to the plane of the coil. The magnitude of the external magnetic field is changing at a rate of ΔB/Δt = 0.508 T/s, thereby inducing a current in the coil. Find the magnitude of the magnetic field at the center of the coil that is produced by the induced...
A circular coil of wire with radius 2 cm and 60 turns is placed in a uniform magnetic field of magnitude 0.8 T. The magnetic field is parallel to the area vector; i.e. perpendicular to the plane of the coil. a) What is the magnetic flux through the coil? b) The magnetic field is decreased to 0 T in 0.1 s. What is the magnitude of the emf induced in the coil during this time interval? c) If the coil...
A circular coil that has N = 210 turns and a radius of r = 9.00 сm lies in a magnetic field that has a magnitude of Bo = 0.0600 T directed perpendicular to the plane of the coil. What is the magnitude of the magnetic flux Og through the coil? OB = 0.321 The magnetic field through the coil is increased steadily to 0.180 T over a time interval of 0.515 s. What is the magnitude El of the...
1. (20 pts) A circular coil with a radius of 8.0 cm is dropped from a location where the magnetic field is 0.2 T into a region where the magnetic field is 1.6 T. The coil takes 0.12 s to fall, has 60 turns and is perpendicular to the magnetic field. The field does not change direction. a. Find the average induced emf in the coil as a result of this action. b. If the induced current flows clockwise as...
A circular coil that has N 280 turns and a radius of r 9.50 cm lies in a magnetic field that has a magnitude of Bo 0.0635 T directed perpendicular to the plane of the coil. what is the magnitude of the magnetic flux Φ B through the coil? T-m2 The magnetic field through the coil is increased steadily to 0.145 T over a time interval of 0.305 s. What is the magnitude |El of the emf induced in the...
A flat circular coil with 167 turns, a radius of 5.73 x 10-2 m, and a resistance of 0.228 2 is exposed to an external magnetic field that is directed perpendicular to the plane of the coil. The magnitude of the external magnetic field is changing at a rate of AB/At = 0.628 T/s, thereby inducing a current in the coil. Find the magnitude of the magnetic field at the center of the coil that is produced by the induced...
