The velocity of 2D flow is given as V=c(x2-y2)+(-2cxy)j , determine The streamline function of the...

Question

Question

The velocity of 2D flow is given as V=c(x²-y²)+(-2cxy)j , determine

engineering Mechanical-Engineering

Answer 1

Answer #1

Answer 2

Similar Homework Help Questions

Consider the flow field with velocity given by: V = [A(y2-x2)-Bx] i + [2Axy+By] j, where...

Consider the flow field with velocity given by: V = [A(y2-x2)-Bx] i + [2Axy+By] j, where A = 4 m-1s -1 and B = 4 m-1s -1. The coordinates are measured in meters. The density is 1,000 kg/m3, and gravity acts in the negative y-direction Calculate the acceleration of a fluid particle and the pressure gradient at point (x, y) = (1, 1).
2) A flow field has velocity field given by: u= x2 - y2, v= -2xy 1....

2) A flow field has velocity field given by: u= x2 - y2, v= -2xy 1. Prove that the flow is irrotational 2. Determine the stream function, 3. Find the potential function, 4. Create a plot of the flow net diagram
Given the velocity potential for a 2-D incompressible flow, (x, y) = xy + x2 -...

Given the velocity potential for a 2-D incompressible flow, (x, y) = xy + x2 - y2 (a) Does the potential satisfy the Laplace Equation (i.e. V20 = 0)? What is the physical intepretation of this? (b) Find u(x,y) and v(x,y) (the corresponding velocity field of the flow). (c) Does the stream function y (x,y) exist? If so: (a) Find the stream function. (b) Find the implicit equation of streamline that passes through (x,y) = (1, 2).

The velocity field of a flow is given by V = (2+1) x y2 i +...

The velocity field of a flow is given by V = (2+1) x y2 i + (3+2) t j m/s where x and y is in meter and t in seconds. Determine the following at point (1, 2) and t= 3 s: 1. The fluid speed. 2. The angle between the velocity vector and the positive x 3. Locations (if avaliable) of any stagnation point for this flow field? 4. The local acceleration, then classiffy the flow . 5. The...
Solve for the equation of a streamline in a flow with velocity field u = cx,...

Solve for the equation of a streamline in a flow with velocity field u = cx, v = -cy, where c is a positive constant. The solution should have the form y = f(x). Using the axes given below, sketch representative streamlines for this flow
The x and y components of velocity for 2D flow are u = 3 m/s and...

The x and y components of velocity for 2D flow are u = 3 m/s and v = 9x2 m/s, where x is in meter. Determine the equation of the streamlines (y) and plot the graph of the streamline when y = 0 for the range of -10 <=x <= 10 and -10 <= y <= 10

11) (6 points) Given the velocity field V =101 +(x2 + y2); -2xy [m/s] a) b)...

11) (6 points) Given the velocity field V =101 +(x2 + y2); -2xy [m/s] a) b) c) Is the flow steady or unsteady? Is this motion kinematically possible for an incompressible fluid? Do you think that velocity field can represent a potential flow at specific positions of (x, y)? What is the acceleration of a particle at position (x, y, z) = (3, 1, 0) m? d)
Given the velocity field j = 101 +(x2 + y2)7 - 2xy K (m/s) a) b)...

Given the velocity field j = 101 +(x2 + y2)7 - 2xy K (m/s) a) b) c) Is the flow steady or unsteady? Is this motion kinematically possible for an incompressible fluid? Do you think that velocity field can represent a potential flow at specific positions of (x, y)? What is the acceleration of a particle at position (x, y, z) = (3, 1, 0) m? d)
If the velocity field for a flow is given as V = był + 3x9 [m/s]...

If the velocity field for a flow is given as V = był + 3x9 [m/s] Determine the equation of the streamline, and evaluate said streamline for the point (1, 2)

help 1. A 2D inviscid flow field is represented by the velocity potential function: ° =...

help 1. A 2D inviscid flow field is represented by the velocity potential function: ° = Ax + Bx2 – By2. Where A = 1m/s, B = 15-7, and the coordinates are measured in meters. The flow density is p = 1.2 kg/m3. (a) (2 points) Calculate the velocity field. (b) (2 points) Verify that the flow is irrotational. (c) (2 points) Verify that the flow is incompressible. (d) (2 points) Obtain the expression of stream function. (e) (2 points)...
