What is wrong with the current code?
PROGRAM A – Memory Data Transfer
| |
| LDA #$A |
| LDX #$200 |
LOOP: | LDY #$300 |
| LDB ,X+ |
| STB ,Y+ |
| DECA |
| BNE LOOP |
RETN: | JMP $D000 |
| .ORG $200 |
| FCB 0,1,2,3,4,5,6,7,8,9,$A |
| END |
Objective: The following program transfers data starting from memory location $200 to memory location $300
Example:
Result After Program Runs | |
Address | Value |
200 | 00 |
201 | 01 |
202 | 02 |
. | . |
300 | 00 |
301 | 01 |
302 | 02 |
. | . |
What is wrong with the current code?
Modify code to work as intended.
Modify code so data is transferred in reverse order. (Hint: Use Index Addressing
– Auto Decrement)
Example:
Result After Program Runs | |
Address | Value |
200 | 00 |
201 | 01 |
202 | 02 |
. | . |
300 | 02 |
301 | 01 |
302 | 00 |
. | . |
