A generator transformer has a magnetising current of 1.5 %. The primary winding voltage is 27 kV and the secondary voltage is 330kV. The transformer rating is 360 MVA. What is the allowable operating...

A generator transformer has a magnetising current of 1.5 %. The primary winding voltage is 27 kV and the secondary voltage is 330kV. The transformer rating is 360 MVA. What is the allowable operating current differential, in terms of Amperes on the primary, that should not cause the protection to operate?

Select one:

a. 200.00 Amperes

b. 31.08 Amperes

c. 115.47 Amperes

d. 66.00 Amperes

engineering   Electrical-Engineering
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

6 360X16 Transformer pinahycument: 3 (66 not operati

0 0
