Homework Answers
a)For temperature measurment ,the physical quantity we can use the volume of mercury or length of mercury column in a thermometer.if we are using thermocouple the physical principle is seebeck effect.In pyrometer radiation effect is the principle.
b)pressure signals we are using to control the flow rates.Analog signals are using for sensor reading,and also many control valves are using as final control element.
c)Float actuated devices,Displacer devices,Dielectric measurments,Conductivity measurments,Sonic resonance
