The 52 kg block starting at rest is pushed 7.8 m up a ramp at an...

The 52 kg block starting at rest is pushed 7.8 m up a ramp at an angle θ = 27.0° to the horizontal in 17 s. If the coeficient of kinetic friction is 0.17:

a) What is the acceleration of block?
m/s/s

b) What is the force used to push the block up the ramp?
N

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

27 gn 12 (55 스 1311 NI

0 0
Add a comment
