What is FT in the achilles tendon (pulling upward)?
The Achilles tendon is attached to the rear of the foot as shown in the figure . When a person elevates himself just barely off the floor on the "ball of one foot," estimate the tension FT in the Achilles tendon (pulling upward). Assume the person has a mass of 79kg and D is twice as long as d.
FT= _____________N
Homework Answers
Given that the mass of the person is m = 79 Kg
--------------------------------------------------------------------------
the normal force is acts on the ball of foot . this normal force is equal tothe weight of th e
person . it is acting upwards.
now taking the moments about force Fbthen
Σ τ=0 Fn*2d - Fa*d = 0
Fa = 2Fn
=2*mg
= 2*79Kg*9.8m/s2
=-------- N
now taking the moments about force Fathen
Σ τ=0 Fb*d - Fn*3d = 0
Fb = 3Fn
=3*mg
= 3*79Kg*9.8m/s2
=---------- N
