A thin light string is wrapped around the outer rim of a uniform hollow cylinder
A thin lightstring is wrapped around the outer rim of a uniform hollow cylinder of mass 4.15kg (as shown in picture attached) having inner and outer radii as shown in thefigure . The cylinder is then released from rest.
A)How far must the cylinder fall before its center is moving at 6.74m/s ?
B)If you just dropped this cylinder without any string, how fast would its center be moving when it had fallen the distance in part A?
C) Why do you get two different answers? The cylinder falls the same distance in both cases.
Homework Answers
Add Answer to:
A thin light string is wrapped around the outer rim of a uniform hollow cylinder
A uniform hollow disk has two pieces of thin light wire wrapped around its outer rim...
A uniform hollow disk has two pieces of thin light wire wrapped around its outer rim and is supported from the ceiling (See figure). Suddenly one of the wires breaks, and the remaining wire does not slip as the disk rolls down. The inner radius of the cylinder is 30 cm and the outer radius is 50 cm. Use energy conservation to find the speed of the center of this disk after it has fallen a distance of 2.20 m.
PartA A light string is wrapped around the outer rim of a solid uniform cylinder of...
PartA A light string is wrapped around the outer rim of a solid uniform cylinder of diameter 75.0 cm that can rotate without friction about an axle through its center. A 3.00 kg stone is tied to the free end of the string, as shown in the figure (Figure 1) When the system is released from rest, you determine that the stone reaches a speed of 3.50 m/s after having fallien 2.50m What is the mass of the cylinder? kg...
A light string is wrapped around the outer rim of a hollow cylinder (ignore spokes) that...
A light string is wrapped around the outer rim of a hollow cylinder (ignore spokes) that can rotate without friction about an axle through its center. A 7 kg stone is tied to the free end of the string. When the system is released from rest, you determine that the stone accelerates downwards at a rate of 5.6 m/s 4. What is the tension in the string? a. 28.4 N b. 29.4 N ?. 39.2 N d. 68.6 N e....
A thin, light wire is wrapped around the rim of a wheel, as shown in the...
A thin, light wire is wrapped around the rim of a wheel, as shown in the following figure. The wheel rotates without friction about a stationary horizontal axis that passes through the center of the wheel. The wheel is a uniform disk with radius 0.270 m. An object of mass 4.40 kg is suspended from the free end of the wire. The system is released from rest and the suspended object descends with constant acceleration. (Figure 1) If the suspended...
A 2.00-kg stone is tied to a thin, light wire wrapped around the outer edge of...
A 2.00-kg stone is tied to a thin, light wire wrapped around the outer edge of the uniform 10.0-kg cylindrical pulley shown in the figure below (Figure 1). The inner diameter of the pulley is 60.0 cm, while the outer diameter is 1.00 m. The system is released from rest, and there is no friction at the axle of the pulley. (A) Find the acceleration of the stone. (m/s2 ) (B) Find the tension in the wire. (N) (C) Find...
A string is wrapped around a uniform cylinder of mass M and radius R as shown...
A string is wrapped around a uniform cylinder of mass M and radius R as shown in figure 4. The cylinder is released from rest with the string vertical and its top end tied to a fixed bar. a. Show that the tension in the string is one-third the weight of the cylinder. b. Show that the magnitude of the acceleration of the center of gravity is 2g/3. c. Show that the speed of the center of gravity is (4gl/3)^1/2...
A light, flexible rope is wrapped several times around a hollow cylinder with a weight of...
A light, flexible rope is wrapped several times around a hollow cylinder with a weight of 40.0 Nand a radius of 0.25 m, that rotates without friction about a fixed horizontal axis. The cylinder is attached to the axle by spokes of a negligible moment of inertia. The cylinder is initially at rest. The free end of the rope is pulled with a constant force P for a distance of 5.00 m, at which point the end of the rope...
A light string is wrapped around a solid cylinder, and a block of mass m=100g hangs...
A light string is wrapped around a solid cylinder, and a block
of mass m=100g hangs from the free end of the string, as shown
Figure A2.17. When released, the block falls a
distance of 1.00m in 2.00s.
Draw free-body (or force) diagrams for the block and the
cylinder.
Calculate the tension in the string.
Determine the mass (M) of the cylinder.
A light string is wrapped around a solid cylinder, and a block of mass m 100 g hangs...
A uniform hollow disk has two pieces of thin light wire wrapped around its outer rim and is supported from the ceiling (See figure). Suddenly one of the wires breaks, and the remaining wire does not slip as the disk rolls down. The inner radius of the cylinder is 30 cm and the outer radius is 50 cm. Use energy conservation to find the speed of the center of this disk after it has fallen a distance of 2.20 m.
PartA A light string is wrapped around the outer rim of a solid uniform cylinder of diameter 75.0 cm that can rotate without friction about an axle through its center. A 3.00 kg stone is tied to the free end of the string, as shown in the figure (Figure 1) When the system is released from rest, you determine that the stone reaches a speed of 3.50 m/s after having fallien 2.50m What is the mass of the cylinder? kg...
A light string is wrapped around the outer rim of a hollow cylinder (ignore spokes) that can rotate without friction about an axle through its center. A 7 kg stone is tied to the free end of the string. When the system is released from rest, you determine that the stone accelerates downwards at a rate of 5.6 m/s 4. What is the tension in the string? a. 28.4 N b. 29.4 N ?. 39.2 N d. 68.6 N e....
A string is wrapped around a uniform cylinder of mass M and radius R as shown in figure 4. The cylinder is released from rest with the string vertical and its top end tied to a fixed bar. a. Show that the tension in the string is one-third the weight of the cylinder. b. Show that the magnitude of the acceleration of the center of gravity is 2g/3. c. Show that the speed of the center of gravity is (4gl/3)^1/2...
A light string is wrapped around a solid cylinder, and a block
of mass m=100g hangs from the free end of the string, as shown
Figure A2.17. When released, the block falls a
distance of 1.00m in 2.00s.
Draw free-body (or force) diagrams for the block and the
cylinder.
Calculate the tension in the string.
Determine the mass (M) of the cylinder.
A light string is wrapped around a solid cylinder, and a block of mass m 100 g hangs...
