When tightening a bolt, you push perpendicularly on a wrench with a force of 160 N at a distance of 0.155 m from the center of the bolt.

Question

Question

Part(a) How much torque are you exerting on the wrench, in newton meters, relative to the center of the bolt?

science physics

Answer 1

Answer #1

Answer 2

Answer #2

SOLUTION :

Torque = F * r = 160 * 0.155 = 24.8 N-m (ANSWER)

answered by: Tulsiram Garg
