Three resistors are made out of three different materials and have different (but uniform) cross-sections. Resistor...
Three resistors are made out of three different materials and have different (but uniform) cross-sections. Resistor 1 has a circular cross-section of radius 3.33 mm. Resistor 2 has a square cross section with a side length of 2.22 mm. The third resistor\'s cross-section is a right triangle with two sides of length 5.50 mm as shown. All of the resistors are 0.763 cm in length. Use the provided table of resistivities to calculate the resistance of each resistor.
This is the information from the table:
Material 1: 4.79 x 10^-3 omega*m
Material 2: 0.391 omega*m
Material 3: 4.63 x 10^-5 omega*m
Resister 1: 3.33 mm
Resister 2: 2.22 mm
Resister 3: 5.50 mm
Homework Answers
