A 5.0 kg block is on a perfectly smooth ramp that makes an angle of 31°...

Question

Question

A 5.0 kg block is on a perfectly smooth ramp that makes an angle of 31° with the horizontal.

(a) What is the block's acceleration (in m/s2) down the ramp? (Enter the magnitude in m/s^2.)

(b) What is the force (in N) of the ramp on the block? (Enter the magnitude in N.)

(c) What force (in N) applied upward along and parallel to the ramp would allow the block to move with constant velocity? (Enter the magnitude.)

science physics

Answer 1

Answer #1

Answer 2
