A capacitor is discharged through a 100 Ω resistor. The discharge current decreases to 23.0% of its initial value in 1.50 ms
Part A
What is the value of the capacitor? Express your answer with the appropriate units.
Homework Answers
A capacitor is discharged through a 30.0 Ω resistor. The discharge current decreases to 26.0% of...
A capacitor is discharged through a 30.0 Ω resistor. The discharge current decreases to 26.0% of its initial value in 3.00 ms . what is the value of the capacitor?
A 14.1 μF capacitor is charged to a potential of 45.0 V and then discharged through...
A 14.1 μF capacitor is charged to a potential of 45.0 V and then discharged through a 75.0 Ω resistor. (a) How long after discharge begins does it take for the capacitor to lose 90.0% of the following? (i) its initial charge? _______s (ii) its initial energy? ______s (b) What is the current through the resistor at both times in part (a)? (i) at tcharge ? _________ A (ii) at tenergy ? ________A
THQ-1 (5-points) An initially charged capacitor is discharged through a resistor: C a) Will the capacitor...
THQ-1 (5-points) An initially charged capacitor is discharged through a resistor: C a) Will the capacitor discharge faster or slower if the resistance is increased (using the same amount of initial charge)? b) Will the capacitor discharge faster or slower if the capacitance is increased (using the same amount of initial charge)? c) As the capacitor discharges, does the magnitude of the current through the resistor increase or decrease in time? d) As the capacitor discharges, what is the magnitude...
1. A 577 μF capacitor is discharged through a resistor, whereby its potential difference decreases from...
1. A 577 μF capacitor is discharged through a resistor, whereby its potential difference decreases from its initial value of 81.7 V to 24.1 V in 4.15 s.Find the resistance of the resistor in kilohms. 2. A capacitor of 10.0 μF and a resistor of 120 Ω are quickly connected in series to a battery of 5.00 V. What is the charge Q on the capacitor 0.00200 s after the connection is made? 3. A heart pacemaker fires exactly 6565...
A 681 x 105 F capacitor is discharged through a resistor, whereby its potential difference decreases...
A 681 x 105 F capacitor is discharged through a resistor, whereby its potential difference decreases from its initial value of 92.9 V to 15.7 V in 4.75 s. Find the resistance of the resistor. Number 0.254898 101 Ω There is additional feedback available! View this feedback by clicking on the bottom divider bar, Click on the divider bar again to hide the additional feedback Clase Incorrect.
A 10 uF capacitor that had been charged to 30 V is discharged through a resistor....
A 10 uF capacitor that had been charged to 30 V is discharged through a resistor. The figure (Figure 1)shows the capacitor voltage as a function of time. Part A What is the value of the resistance? Express your answer using two significant figures. Figure (< 1 of 1 > AVC (V) ΑΣΦ R 180 Submit Previous Answers Request Answer 0 2 4 I f(ms) 6 X Incorrect; Try Again; One attempt remaining
A 6.0 μF capacitor is fully charged and connected through a 100 Ω resistor. The time...
A 6.0 μF capacitor is fully charged and connected through a 100 Ω resistor. The time it takes for the capacitor to discharge at 37% of its initial charge is: a.3.2 x 10-5 s b.4.8 x 10-5 s c.6.6 x 10-5 s d.6.0 x 10-4 s
A capacitor of capacitance 382 μF is discharged through a resistor of 25 kΩ. Find the...
A capacitor of capacitance 382 μF is discharged through a resistor of 25 kΩ. Find the time required by the capacitor to discharge 66 percent of its maximum charge. Give your answer to atleast two decimal places.
A 539 μF capacitor is discharged through a resistor, whereby its potential difference decreases from its...
A 539 μF capacitor is discharged through a resistor, whereby its potential difference decreases from its initial value of 86.7 V to 12.1 V in 4.57 s. Find the resistance of the resistor in kilohms.
A capacitor of 10 mF capacitance is being discharged through a resistor. It is observed that...
A capacitor of 10 mF capacitance is being discharged through a resistor. It is observed that the current in the circuit drops to 50% of its initial value in 12 seconds. Calculate the resitor's resistance.
THQ-1 (5-points) An initially charged capacitor is discharged through a resistor: C a) Will the capacitor discharge faster or slower if the resistance is increased (using the same amount of initial charge)? b) Will the capacitor discharge faster or slower if the capacitance is increased (using the same amount of initial charge)? c) As the capacitor discharges, does the magnitude of the current through the resistor increase or decrease in time? d) As the capacitor discharges, what is the magnitude...
A 681 x 105 F capacitor is discharged through a resistor, whereby its potential difference decreases from its initial value of 92.9 V to 15.7 V in 4.75 s. Find the resistance of the resistor. Number 0.254898 101 Ω There is additional feedback available! View this feedback by clicking on the bottom divider bar, Click on the divider bar again to hide the additional feedback Clase Incorrect.
A 10 uF capacitor that had been charged to 30 V is discharged through a resistor. The figure (Figure 1)shows the capacitor voltage as a function of time. Part A What is the value of the resistance? Express your answer using two significant figures. Figure (< 1 of 1 > AVC (V) ΑΣΦ R 180 Submit Previous Answers Request Answer 0 2 4 I f(ms) 6 X Incorrect; Try Again; One attempt remaining
