QUESTION 1: Heat Exchanges A concentric tube parallel floween s hot water saturated liquid from 30...
please do 11.33 11.32 A single-pass, cross-flow heat exchanger uses hot exhaust gases (mixed) to heat...
please do 11.33
11.32 A single-pass, cross-flow heat exchanger uses hot exhaust gases (mixed) to heat water (unmixed) from 30 to 80°C at a rate of 3 kg/s. The exhaust gases, hav- ing thermophysical properties similar to air, enter and exit the exchanger at 225 and 100°C, respectively. If the overall heat transfer coefficient is 200 W/m2.K, estimate the required surface area. 11.33 Consider the fluid conditions and overall heat transfer coefficient of Problem 11.32 for a concentric tube heat...
A concentric tube heat exchanger for cooling lubricating oil consists of a thin-walled inner tube of...
A concentric tube heat exchanger for cooling lubricating oil
consists of a thin-walled inner tube of 25 mm diameter carrying
water and an outer tube of 45 mm diameter carrying the oil. The
exchanger operates in countercurrent flow with an overall heat
transfer coefficient of 55 W/m2 K and the tabulated average
properties given below. Mass flow rates of oil and water are both
0.1 kg/s, oil enters the exchanger at 100°C, and water enters the
exchanger at 30°C. (a)...
Consider a very long, concentric tube heat exchanger having hot and cold water inlet temperatures of...
Consider a very long, concentric tube heat exchanger having hot and cold water inlet temperatures of 85 and 15°C. The flow rate of the hot water is twice that of the cold water. Assuming equivalent hot and cold water specific heats, determine the hot water outlet temperature for the following modes of operation: (a) counterflow and (b) parallel flow. (a) Determine the hot water outlet temperature for counterflow operation, in °C. Thy0 = | i °C (b) Determine the hot...
A concentric tube heat exchanger for cooling lubricating oil is comprised of a thin-walled inner tube...
A concentric tube heat exchanger for cooling lubricating oil is comprised of a thin-walled inner tube of 25 mm diameter carrying water and an outer tube of 45 mm diameter carrying the oil. The mass flow rates of both fluids are 0.1 kg/s. The exchanger operates in counter-flow with an overall heat transfer coefficient of 60 W/m2
Twenty [kw] of heat is to be removed from 375 [k] water flowing at 0.15 [kg/s] into the inner pipe of concentric tube heat exchanger. Cooling water enters the annulus at 290 [k] and leaves at 320...
Twenty [kw] of heat is to be removed from 375 [k] water flowing at 0.15 [kg/s] into the inner pipe of concentric tube heat exchanger. Cooling water enters the annulus at 290 [k] and leaves at 320 [k] with a flow in the opposite direction of the inner flow. The diameter of the thin- walled inner pipe is 2.5 [cm] a) b) c) Calculate the exit temperature of the hot fluid and the mass flow rate of the cold fluid...
A concentric tube, parallel heat exchanger is used to warm cold well water running on the...
A concentric tube, parallel heat exchanger is used to warm cold well water running on the inside pipe from 10°C to 25°C overa meter of pipe using steam running through the outside pipe that enters the system at 140°C and leaves at 100°C. The inside pipe is made of copper and has an inner diameter of 4 cm, with a wall thickness of 0.25 cm. The outside pipe is made of a very-well insulating material, has a diameter of 7...
A concentric-pipe parallel-flow heat exchanger is to heat water (cp = 4.18 kJ/kg.K) from 20°C to...
A concentric-pipe parallel-flow heat exchanger is to heat water (cp = 4.18 kJ/kg.K) from 20°C to 80°C at a rate of 1.2 kg/s. The heating is to be accomplished by geothermal water (Cp =4.31 kJ/kg.K) available at 160°C at a mass flow rate of 2.0 kg/s. The inner pipe is thin-walled and has a diameter of 1.5 cm. If the overall heat transfer coefficient of the heat exchanger is 640 W/m2.K, determine the length of the pipe required to achieve...
An organic liquid is heated from 20°C to 40°C by hot water in a 1:1 pass...
An organic liquid is heated from 20°C to 40°C by hot water in a 1:1 pass shell-and- tube heat exchanger in counter-current flow. The inlet temperature of the water stream is 85oC and flows in the shell side. The organic liquid flows through a bundle of 200 tubes of outside diameter 21 mm with a wall thickness of 2 mm. The flows of the organic liquid and water are 40 kg s and 15 kg s1, respectively (a) Calculate the...
A concentric tube heat exchanger of length L = 2 m is used to thermally process...
A concentric tube heat exchanger of length L = 2 m is used to thermally process a pharmaceutical product flowing at a mean velocity of u_m,c = 0.1 m/s with an inlet temperature of T_c,i = 20 degree C. The inner tube of diameter D_i = 10 mm is thin walled, and the exterior of the outer tube (D_0 = 20 mm) is well insulated. Water flows in the annular region between the tubes at a mean velocity of u_m,h...
Hot water flows thorough a parallel flow heat exchanger at a rate of 10 kg/min and...
Hot water flows thorough a parallel flow heat exchanger at a rate of 10 kg/min and is cooled by a cold water stream of flow rate 25 kg/min. The inlet temperatures of hot and cold water streams are 70 oC and 25 oC, respectively. The outlet temperature of the hot water is expected to be 50 oC. The individual convective heat transfer coefficient on both sides of the heat transfer area is 600 W/m2 .K. Take the specific heat for...
please do 11.33
11.32 A single-pass, cross-flow heat exchanger uses hot exhaust gases (mixed) to heat water (unmixed) from 30 to 80°C at a rate of 3 kg/s. The exhaust gases, hav- ing thermophysical properties similar to air, enter and exit the exchanger at 225 and 100°C, respectively. If the overall heat transfer coefficient is 200 W/m2.K, estimate the required surface area. 11.33 Consider the fluid conditions and overall heat transfer coefficient of Problem 11.32 for a concentric tube heat...
A concentric tube heat exchanger for cooling lubricating oil
consists of a thin-walled inner tube of 25 mm diameter carrying
water and an outer tube of 45 mm diameter carrying the oil. The
exchanger operates in countercurrent flow with an overall heat
transfer coefficient of 55 W/m2 K and the tabulated average
properties given below. Mass flow rates of oil and water are both
0.1 kg/s, oil enters the exchanger at 100°C, and water enters the
exchanger at 30°C. (a)...
Consider a very long, concentric tube heat exchanger having hot and cold water inlet temperatures of 85 and 15°C. The flow rate of the hot water is twice that of the cold water. Assuming equivalent hot and cold water specific heats, determine the hot water outlet temperature for the following modes of operation: (a) counterflow and (b) parallel flow. (a) Determine the hot water outlet temperature for counterflow operation, in °C. Thy0 = | i °C (b) Determine the hot...
Twenty [kw] of heat is to be removed from 375 [k] water flowing at 0.15 [kg/s] into the inner pipe of concentric tube heat exchanger. Cooling water enters the annulus at 290 [k] and leaves at 320 [k] with a flow in the opposite direction of the inner flow. The diameter of the thin- walled inner pipe is 2.5 [cm] a) b) c) Calculate the exit temperature of the hot fluid and the mass flow rate of the cold fluid...
A concentric-pipe parallel-flow heat exchanger is to heat water (cp = 4.18 kJ/kg.K) from 20°C to 80°C at a rate of 1.2 kg/s. The heating is to be accomplished by geothermal water (Cp =4.31 kJ/kg.K) available at 160°C at a mass flow rate of 2.0 kg/s. The inner pipe is thin-walled and has a diameter of 1.5 cm. If the overall heat transfer coefficient of the heat exchanger is 640 W/m2.K, determine the length of the pipe required to achieve...
An organic liquid is heated from 20°C to 40°C by hot water in a 1:1 pass shell-and- tube heat exchanger in counter-current flow. The inlet temperature of the water stream is 85oC and flows in the shell side. The organic liquid flows through a bundle of 200 tubes of outside diameter 21 mm with a wall thickness of 2 mm. The flows of the organic liquid and water are 40 kg s and 15 kg s1, respectively (a) Calculate the...
A concentric tube heat exchanger of length L = 2 m is used to thermally process a pharmaceutical product flowing at a mean velocity of u_m,c = 0.1 m/s with an inlet temperature of T_c,i = 20 degree C. The inner tube of diameter D_i = 10 mm is thin walled, and the exterior of the outer tube (D_0 = 20 mm) is well insulated. Water flows in the annular region between the tubes at a mean velocity of u_m,h...
