A thin rigid rod of MM = 1.6 kg and L = 3.2 m rotates at the
angular speed ω = 5 rev/s around the rotation axis which is at d =
0.1 m from the center of the mass of the rod, as shown. Note that
ICM = ML^2/12 for a thin rod.
A. Calculate the moment of inertia I of the rod for the rotation
axis.
B. What is the rotational kinetic energy of the thin rod?
