Light from a sodium lamp (λ=589nm) illuminates two narrow slits. The fringe spacing on a screen...

Question

Question

Light from a sodium lamp (λ=589nm) illuminates two narrow slits. The fringe spacing on a screen 160 cm behind the slits is 4.4 mm .

What is the spacing (in mm) between the two slits?

science physics

Answer 1

Answer #1

d=589 nm = 589 810 m. D = 160cm. -1.6om I= 4.4mm = 4.4 X 103 m Spacing between y= AL the two slits (d) d = XL y - 589 8109 X1

Answer 2

Similar Homework Help Questions

Light from a sodium lamp (lambda = 589 nm) illuminates a narrow slit and is observed...

Light from a sodium lamp (lambda = 589 nm) illuminates a narrow slit and is observed on a screen 77.0 cm behind the slit. The distance between the first and third dark fringes is 2.50 mm What is the width (in mm) of the slit?
Light from a helium-neon laser (λ = 633 nm) is used to illuminate two narrow slits....

Light from a helium-neon laser (λ = 633 nm) is used to illuminate two narrow slits. The interference pattern is observed on a screen 2.5 m behind the slits. Eleven bright fringes are seen, spanning a distance of 50 mm . What is the spacing (in mm) between the slits?
A laser with a wavelength of 470. nm illuminates two narrow slits. The interference pattern from...

A laser with a wavelength of 470. nm illuminates two narrow slits. The interference pattern from the double slits is viewed on a screen that is 3.30 m away. Over a distance of 41.0 mm there are 11.0 bright fringes with the first and last fringe situated exactly at each end of that distance. What is the spacing between the two slits?

A laser with a wavelength of 470. nm illuminates two narrow slits. The interference pattern from...

A laser with a wavelength of 470. nm illuminates two narrow slits. The interference pattern from the double slits is viewed on a screen that is 3.30 m away. Over a distance of 41.0 mm there are 11.0 bright fringes with the first and last fringe situated exactly at each end of that distance. What is the spacing between the two slits? I have tried the following answers and they are incorrect: 4.16E-6m 416mm 0.416E-3m 0.000454m 0.416mm
Two narrow slits are 0.12 mm apart. Light of wavelength 550 nm illuminates the slits, causing...

Two narrow slits are 0.12 mm apart. Light of wavelength 550 nm illuminates the slits, causing an interference pattern on a screen 1.0 m away. Light from each slit travels to the m=1 maximum on the right side of the central maximum. How much farther did the light from the left slit travel than the light from the right slit?
Two narrow slits are 0.12 mm apart. Light of wavelength 550 nm illuminates the slits, causing...

Two narrow slits are 0.12 mm apart. Light of wavelength 550 nm illuminates the slits, causing an interference pattern on a screen 1.0 m away. Light from each slit traveis to the m = 1 maximum on the right side of the centrai maximum. How much farther did the light from the left slit travei than the light from the right slit?

Two narrow slits are 0.12 mm apart. Light of wavelength 550 nm illuminates the s...continues

Two narrow slits are 0.12 mm apart. Light of wavelength 550 nm illuminates the slits, causing an interference pattern on a screen 1.0 m away. Light from each slittravels to the m=1 maximum on the right side of the central maximum. How much farther did the light from the left slit travel than the light from the right slit?(answer in nm)
A helium-neon laser (λ=633nm) illuminates a diffraction grating. The distance between the two m=1 bright fringes...

A helium-neon laser (λ=633nm) illuminates a diffraction grating. The distance between the two m=1 bright fringes is 36 cm on a screen 1.7 m behind the grating. What is the spacing between slits of the grating?
A helium-neon laser (λ=633nm) illuminates a diffraction grating. The distance between the two m=1 bright fringes...

A helium-neon laser (λ=633nm) illuminates a diffraction grating. The distance between the two m=1 bright fringes is 32 cm on a screen 2.3 m behind the grating. What is the spacing between slits of the grating?

A helium-neon laser (λ=633nm) illuminates a diffraction grating. The distance between the two m=1 bright fringes...

A helium-neon laser (λ=633nm) illuminates a diffraction grating. The distance between the two m=1 bright fringes is 37 cm on a screen 1.8 m behind the grating. What is the spacing between slits of the grating?
