An electron is accelerated inside a parallel plate capacitor, The electron leaves the negative plate with...

Question

Question

An electron is accelerated inside a parallel plate capacitor, The electron leaves the negative plate with a negligible initia

science physics

Answer 1

Answer #1

V=1073 Xloomis Using classical mechanics £mv² =qV VE 2X16X10 19 X 115x103 9.1 no-37 54044 x10-19+31+3+1 v² 16 4.044 X10 v=2.0

Answer 2

Similar Homework Help Questions

An electron is accelerated inside a parallel plate capacitor. The electron leaves the negative plate with...

An electron is accelerated inside a parallel plate capacitor. The electron leaves the negative plate with a negligible initial velocity and then after the acceleration it hits the positive plate with a final velocity B. The distance between the plates is 17.4 cm, and the voltage difference is 148 kv. Determine the final velocity B of the electron using classical mechanics. (The rest mass of the electron is 9.11x10-31 kg, the rest energy of the electron is 511 keV.) Submit...
An electron initially at rest passes from one plate of a charged capacitor to another. The...

An electron initially at rest passes from one plate of a charged capacitor to another. The voltage difference between plates is 10^7 V. Use (relativistic) conservation of energy to find the final velocity of the electron.
An electron is accelerated from rest across the gap of a capacitor (two parallel plates charged...

An electron is accelerated from rest across the gap of a capacitor (two parallel plates charged -Q and +Q respectively). A hole in the top plate allows the electron to emerge with a constant velocity of v = 71 m/s. If the gap between the plates is d = 0.47 m, what is the magnitude of the electric field between the plates?

An electron is released from rest at the negative plate of a parallel plate capacitor and...

An electron is released from rest at the negative plate of a parallel plate capacitor and accelerates to the positive plate. The plates are separated by a distance of 1.2 cm and the electric field within the capacitor has a magnitude of 2.1 * 10^6 V/m. What is the speed of the electron just as it reaches the positive plate?
An electron is released from rest at the negative plate of a parallel plate capacitor and...

An electron is released from rest at the negative plate of a parallel plate capacitor and accelerates to the positive plate (see the drawing). The plates are separated by a distance of 1.7 cm, and the electric field within the capacitor has a magnitude of 2.7 x 106 V/m. What is the kinetic energy of the electron just as it reaches the positive plate? The figure shows a vertical plate on the left that is negatively charged and another vertical...
An electron is released from rest at the negative plate of a parallel plate capacitor and...

An electron is released from rest at the negative plate of a parallel plate capacitor and accelerates to the positive plate (see the drawing). The plates are separated by a distance of 2.4 cm, and the electric field within the capacitor has a magnitude of 1.8 x 10% v/m. What is the kinetic energy of the electron just as it reaches the positive pliate? KEpositive- Electric ield Electron

An electron is released from rest at the negative plate of a parallel plate capacitor. The...

An electron is released from rest at the negative plate of a parallel plate capacitor. The charge per unit area on each plate is = 1.9 × 10-7 C/m2, and the plates are separated by a distance of 1.5 × 10-2 m. How fast is the electron moving just before it reaches the positive plate?
An electron is released from rest at the negative plate of a parallel plate capacitor. The...

An electron is released from rest at the negative plate of a parallel plate capacitor. The charge per unit area on each plate is = 2.1 × 10-7 C/m2, and the plates are separated by a distance of 1.7 × 10-2 m. How fast is the electron moving just before it reaches the positive plate?
An electron is released from rest at the negative plate of a parallel plate capacitor. The...

An electron is released from rest at the negative plate of a parallel plate capacitor. The charge per unit area on each plate is = 2.0 × 10-7 C/m2, and the plates are separated by a distance of 1.9 × 10-2 m. How fast is the electron moving just before it reaches the positive plate? help!!

An electron is released from rest at the negative plate of a parallel plate capacitor. The...

An electron is released from rest at the negative plate of a parallel plate capacitor. The charge per unit area of each plate is = 2.0 x 10-7 C/m2, and the plates are seperated by a distance of 2.1 x 10-2 m. How fast is the electron moving just before it reaches the positive plate?
