What current should pass through a solenoid that is 0.5 m long with 10000 turns of...
What current should pass through a solenoid that is 0.5 m long with 10000 turns of copper wire so that it will have a magnetic field of 0.4 T?
Homework Answers
Add Answer to:
What current should pass through a solenoid that is 0.5 m long
with 10000 turns of...
A solenoid is 0.65 m long and contains 1500 turns exactly. A current of 2.0 A...
A solenoid is 0.65 m long and contains 1500 turns exactly. A current of 2.0 A flows through the wire. What will be the magnitude of the magnetic field produced by the solenoid in its interior?
Calculate the current which must pass through an ideal solenoid so that in its interior a...
Calculate the current which must pass through an ideal solenoid so that in its interior a magnetic field of 200 mT is generated. The solenoid has 800 turns (loops) of a wire of radius 4.0 cm.
A long solenoid consists of 1900 turns and has a length of 0.65 m. The current...
A long solenoid consists of 1900 turns and has a length of 0.65 m. The current in the wire is 0.41 A. What is the magnitude of the magnetic field inside the solenoid? Submit Answer Tries 0/10 A small diameter, 61 cm long solenoid has 248 turns and is connected in series with a resistor and battery. The size of the magnetic field inside the solenoid is 2.424E-4 T when a voltage of 65.0 V is applied to the circuit....
A long solenoid has a length of 0.60 m and contains 1000 turns of wire. There...
A long solenoid has a length of 0.60 m and contains 1000 turns of wire. There is a current of 6.6 A in the wire. What is the magnitude of the magnetic field within the solenoid?
a) A long solenoid has a length of 0.72 m and contains 1900 turns of wire....
a) A long solenoid has a length of 0.72 m and contains 1900 turns of wire. There is a current of 6.0 A in the wire. What is the magnitude of the magnetic field within the solenoid?
A long solenoid has a length of 0.73 m and contains 1490 turns of wire. There...
A long solenoid has a length of 0.73 m and contains 1490 turns of wire. There is a current of 5.4 A in the wire. What is the magnitude of the magnetic field within the solenoid?
Consider a 4.21-meter-long solenoid with 9130.0 turns of wire carrying a current 2.61 A. Running right...
Consider a 4.21-meter-long solenoid with 9130.0 turns of wire carrying a current 2.61 A. Running right down the middle of the solenoid, along its central axis, is another wire, long and straight, carrying 884.0 A of current. Find the magnitude of the magnetic field, in T, a distance 0.0673 m from the long straight wire, assuming that point is also inside the solenoid.
What current is required in the windings of a long solenoid that has 1100 turns uniformly...
What current is required in the windings of a long solenoid that has 1100 turns uniformly distributed over a length of 0.410 m to produce at the center of the solenoid a magnetic field of magnitude 1.00 ✕ 10-4 T?
A long solenoid has a length of 0.66 m and contains 1500 turns of wire. There...
A long solenoid has a length of 0.66 m and contains 1500 turns of wire. There is a current of 3.9 A in the wire. What is the magnitude of the magnetic field within the solenoid? Units the tolerance is +/-3% Click if you would like to Show Work for this question: Open Show Work
What current is required in the windings of a long solenoid that has 1446 turns uniformly...
What current is required in the windings of a long solenoid that has 1446 turns uniformly distributed over a length of 0.257 m in order to produce inside the solenoid a magnetic field of magnitude 0.0001243 T? The permeablity of free space is 1.25664 × 10−6 T m/A. Answer in units of mA.
A long solenoid consists of 1900 turns and has a length of 0.65 m. The current in the wire is 0.41 A. What is the magnitude of the magnetic field inside the solenoid? Submit Answer Tries 0/10 A small diameter, 61 cm long solenoid has 248 turns and is connected in series with a resistor and battery. The size of the magnetic field inside the solenoid is 2.424E-4 T when a voltage of 65.0 V is applied to the circuit....
A long solenoid has a length of 0.73 m and contains 1490 turns of wire. There is a current of 5.4 A in the wire. What is the magnitude of the magnetic field within the solenoid?
A long solenoid has a length of 0.66 m and contains 1500 turns of wire. There is a current of 3.9 A in the wire. What is the magnitude of the magnetic field within the solenoid? Units the tolerance is +/-3% Click if you would like to Show Work for this question: Open Show Work
