Two charges exist along the x-axis, q1 = +8.6 mC and is locatedat (-8.5, 0)...

Question

Question

Two charges exist along the x-axis, q1 = +8.6 mC and is located at (-8.5, 0) m and q2 = -7 mC and is located at (-5.4, 0) m. Determine

a) The electrical potential at the origin: __________ V

b) The electrical potential at the point (0,2.5) m: __________ V

science physics

Answer 1

✔ Recommended Answer

Answer #1

R1 25 9,= 8mC 92.7 mC PL kou -8.600) (-5-4,0) a) Up Vedi veer 2 8x10-5 7x10-3 kal 292 I utto 8.5 5.4 8.5 514 3,191, 657,824 V
