please explain!Homework Answers
If voltage drop across a bulb is more then that bulb glow brighter. Given that all the bulbs are identical hence they have same resistance and are connected in series. Hence current through all the bulbs is same hence voltage drop is same. Hence all the bulbs are of equal brightness.
