3 A 11-KV, has a full-load quadrature-axil IV. three-phase, 20-pole, star-connected, salient-pole synchronous alternator full-load current...
A 1500-kVA, 6.6 kV, 50 Hz, 6-pole, three-phase, star-connected synchronous generator has a resistance 0.5Q/phase and a...
A 1500-kVA, 6.6 kV, 50 Hz, 6-pole, three-phase, star-connected
synchronous generator has a resistance 0.5Q/phase and a synchronous
reactance of 5Q/phase. The generator is supplying its rated power
at its rated voltage and at a power factor lagging. The rotational
loss is 2 kW. Calculate:
(a) the power developed,
(b) the power angle,
(c) the voltage regulation, and
(d) the shaft torque.
A 1500-kVA, 6.6 kV, 50 Hz, 6-pole, three-phase, star-connected synchronous generator has a resistance 0.50/phase and a synchronous...
A 750-kVA, 11-kV, 4-pole, 3-phase, star-connected alternator has percentage resistance and reactance of 1 and 15...
A 750-kVA, 11-kV, 4-pole, 3-phase, star-connected alternator has percentage resistance and reactance of 1 and 15 respectively. Using approximate method, calculate the synchronising power and torque per mechanical degree of displacement at full-load 0.8 pf lag. The terminal voltage in each case is 11 kV.
E1Q2 1 0 7 1. A 20 MVA, 6.9 KV 3-phase 4-pole star connected synchronous motor...
E1Q2
1 0 7 1. A 20 MVA, 6.9 KV 3-phase 4-pole star connected synchronous motor is operating with field current of 20 Amps, at full load and 0.9 power factor leading. The motor has a synchronous reactance of 1.5 ohm and negligible armature resistance. 30 points a. Find the motor full load torque and power angle. b. If the field current is increased by 15% and the load torque is increased by 15% find the motor current and power...
QUESTION 5 A 3-phase, 22 kV (phase), 500 MVA star-connected synchronous generator has a per phase...
QUESTION 5 A 3-phase, 22 kV (phase), 500 MVA star-connected synchronous generator has a per phase reactance Xg of 1.5 pu and supplies 0.8 pu per phase real power (P) at the rated voltage, with a lagging power factor of 0.6 to the load. Find the actual excitation voltage Vo in kV (line value). 96.392
A 400 v, 50 Hz, three phase alternator, rated at 75 kVA, is star connected and...
A 400 v, 50 Hz, three phase alternator, rated at 75 kVA, is star connected and driven at 1000 r/min. The windings of the alternator have a resistance, per phase, of 0.03 Ω and synchronous reactance, at 50 Hz per phase, of j0.325 Ω. The stator of the alternator has 108 slots, with 8 conductors, per slots, in a double layer. The maximum pole flux is 8.772 x 10-3 Wb. To improve the wave form only 80% of the pole...
1- A 25-kVA, 3-phase, wye-connected, 400-V alternator has a synchronous reactance of 1.6 ohms per phase....
1- A 25-kVA, 3-phase, wye-connected, 400-V alternator has a synchronous reactance of 1.6 ohms per phase. The alternator is to have zero voltage regulation at half-load. Neglecting the armature resistance, find the operating power factor and the developed power 2. A 500-kVA, 3600-V, 3-phase, 60-Hz alternator has an effective armature resistance per phase of 0.40 ohm Mechanical and iron losses is 10 kW, field current at full load unity power factor is 70 A. The exciter voltage is constant at...
please solve the multiple choices [17-18-19-20] (a) What kind of rotor construction is used in this machine? Cylindrical or salient pole rotor? Why? (b) The field current and the mechanical in...
please solve the multiple choices [17-18-19-20]
(a) What kind of rotor construction is used in this machine? Cylindrical or salient pole rotor? Why? (b) The field current and the mechanical input power are adjusted so that the machine delivers 15 k W at 0.9 lagging power factor. Is it a generator or motor? Draw the per- phase equivalent circuit of machine. (c) Determine the excitation voltage and the power angle (degree) Problem 1. (10 Points) A 3-phase, 20 kVA, 460...
A 100-MVA 12.5-KV 0.85-PF lagging 50-Hz two-pole Y-connected synchronous generator has a synchronous reactance of 1.7...
A 100-MVA 12.5-KV 0.85-PF lagging 50-Hz two-pole Y-connected synchronous generator has a synchronous reactance of 1.7 Q and a negligible armature resistance. I) What is the magnitude of the internal generated voltage at rated conditions? 2) What is its torque angle at these conditions? 3) What is its voltage regulation? 4) Ignoring the losses in this generator, what torque must be applied to its shaft by the prime mover at full load? 5) What is the maximum power the generator...
A three-phase, Y-connected, 6.9-kV, 8-pole, 60-Hz, synchronous motor has a synchronous impedance of 0.01+j6 Ω/phase. The...
A three-phase, Y-connected, 6.9-kV, 8-pole, 60-Hz, synchronous motor has a synchronous impedance of 0.01+j6 Ω/phase. The motor is energized at its rated voltage and frequency, and draws a line current of 100 A. The motor rotates a load, while operating at a lagging power factor of 0.9. Calculate the torque developed by the motor: (a) considering the armature resistance (b) neglecting the armature resistance
A three-phase, delta-connected, two-pole, synchronous generator is connected to a 60 Hz, 13.5 kV (line-to-line), system....
A three-phase, delta-connected, two-pole, synchronous generator is connected to a 60 Hz, 13.5 kV (line-to-line), system. The generator is delivering its rated output power, under which conditions pfload = 0.8 lagging and |SI = 20 MVA. The generator per-phase model parameters at rated load are. RA = 0.5 2 Xss = 522 9. What is the generator's line-to-line voltage regulation? Is the voltage regulation positive or negative? 10. If the field current is held at the rated load value, but...
A 1500-kVA, 6.6 kV, 50 Hz, 6-pole, three-phase, star-connected
synchronous generator has a resistance 0.5Q/phase and a synchronous
reactance of 5Q/phase. The generator is supplying its rated power
at its rated voltage and at a power factor lagging. The rotational
loss is 2 kW. Calculate:
(a) the power developed,
(b) the power angle,
(c) the voltage regulation, and
(d) the shaft torque.
A 1500-kVA, 6.6 kV, 50 Hz, 6-pole, three-phase, star-connected synchronous generator has a resistance 0.50/phase and a synchronous...
E1Q2
1 0 7 1. A 20 MVA, 6.9 KV 3-phase 4-pole star connected synchronous motor is operating with field current of 20 Amps, at full load and 0.9 power factor leading. The motor has a synchronous reactance of 1.5 ohm and negligible armature resistance. 30 points a. Find the motor full load torque and power angle. b. If the field current is increased by 15% and the load torque is increased by 15% find the motor current and power...
QUESTION 5 A 3-phase, 22 kV (phase), 500 MVA star-connected synchronous generator has a per phase reactance Xg of 1.5 pu and supplies 0.8 pu per phase real power (P) at the rated voltage, with a lagging power factor of 0.6 to the load. Find the actual excitation voltage Vo in kV (line value). 96.392
please solve the multiple choices [17-18-19-20]
(a) What kind of rotor construction is used in this machine? Cylindrical or salient pole rotor? Why? (b) The field current and the mechanical input power are adjusted so that the machine delivers 15 k W at 0.9 lagging power factor. Is it a generator or motor? Draw the per- phase equivalent circuit of machine. (c) Determine the excitation voltage and the power angle (degree) Problem 1. (10 Points) A 3-phase, 20 kVA, 460...
A 100-MVA 12.5-KV 0.85-PF lagging 50-Hz two-pole Y-connected synchronous generator has a synchronous reactance of 1.7 Q and a negligible armature resistance. I) What is the magnitude of the internal generated voltage at rated conditions? 2) What is its torque angle at these conditions? 3) What is its voltage regulation? 4) Ignoring the losses in this generator, what torque must be applied to its shaft by the prime mover at full load? 5) What is the maximum power the generator...
A three-phase, delta-connected, two-pole, synchronous generator is connected to a 60 Hz, 13.5 kV (line-to-line), system. The generator is delivering its rated output power, under which conditions pfload = 0.8 lagging and |SI = 20 MVA. The generator per-phase model parameters at rated load are. RA = 0.5 2 Xss = 522 9. What is the generator's line-to-line voltage regulation? Is the voltage regulation positive or negative? 10. If the field current is held at the rated load value, but...
