Question: Given y{n}=2*x[n], what does the impulse response tell us about its stability?
aside: Stability is when you have a bounded input, you get a bounded output. And its bounded if its absolutely summable. So is the delta function (impulse response is an impulse times a constant) absolutely summable? What is the absolute value of an impulse response...just 1?
Homework Answers
Add Answer to:
Question: Given y{n}=2*x[n], what does the impulse response tell
us about its stability?
aside: Stability is...
