A camper hangs 26-kg pack between two trees using separate ropes of different lengths, as shown...

Question

Question

science physics

Answer 1

Answer #1

tension in left string is TL and in right side length is TR.

in horizontal,

Fnet = TLcos71 - TRcos28 = 0

TL = 2.712 TR

in vertical direction,

Fnet = TLsin71 + TRsin28 - mg = 0

2.712 TR sin71 + TRsin28 = 26 x 9.81

TR = 84.07 N .........In right side rope

TL = 2.712 Tr = 228 N ......In left side rope.

Answer 2
