1/3 Assigneu: 202.01.10 Due: 2020.01.2 w 1. The total load on the beam is W lbs,...
2. The governing differential equation that relates the deflection y of a beam to the load w ia w...
2. The governing differential equation that relates the deflection y of a beam to the load w ia where both y and w are are functions of r. In the above equation, E is the modulus of elasticity and I is the moment of inertia of the beam. For the beam and loading shown in the figure, first de m, E = 200 GPa, 1 = 100 × 106 mm4 and uo 100 kN/m and determine the maximum deflection. Note...
Problem 2 Consider a simply supported symmetric I beam ABCD carrying a uniformly distributed load w and a concentrated...
Problem 2 Consider a simply supported symmetric I beam ABCD carrying a uniformly distributed load w and a concentrated load F as shown in Figure 2. Young's modulus of the beam is 200 GPa F- 8 kNN 8cm 3cm 3cm w- 6 kN/m 6cm 2cm Figure 2 1) Replace the support C with the reaction force Rc, and using static equilibrium find the reactions at point A and B in terms of Ro 2) Using the boundary conditions, calculate the...
4N Problem 6. The beam shown is loaded with a linear distributed load for the left...
4N Problem 6. The beam shown is loaded with a linear distributed load for the left half and a constant distributed load for the right. At the center a 4 N load is applied. 6 N/m a) Use equilibrium to find the shear and moment equations for the beam. b) Draw the shear and moment diagrams for the beam. c) Integrate your answers to find the deflection of the beam. Leave your final answer as a piecewise function. (IE can...
Q2. A simply supported beam AB (Figure 2) supports a uniformly distributed load of q =...
Q2. A simply supported beam AB (Figure 2) supports a uniformly distributed load of q = 18kN/m and a concentrated load of P = 23kN at the centre. Consider length of the beam, L = 3m, Young's modulus, E = 200GPa and moment of inertial, I = 30 x 10 mm-. Assume the deflection of the beam can be expressed by elastic curve equations of the form: y(x) = Ax4 + Bx3 + Cx2 + Dx + E. 1) Sketch...
(2) A simply supported beam of flexural rigidity El carries a constant uniformly distributed load of...
(2) A simply supported beam of flexural rigidity El carries a constant uniformly distributed load of intensity p per unit length as shown Figure 2 below. Assume the deflection shape to be a polynomial in x, and is given by v (x) = a., + as+ a2 x, where ao, a.呙are constants to be determined. (a) State the boundary conditions for the deflection equation. Using the boundary conditions stated in (a) and the Rayleigh-Ritz method, determine (b) the constants a,...
Problem 2 Consider a simply supported symmetric I beam ABCD carrying a uniformly distributed load w and a concentrated...
Problem 2 Consider a simply supported symmetric I beam ABCD carrying a uniformly distributed load w and a concentrated load F as shown in Figure 2. Young's modulus of the beam is 200 GPa. F 8 kN 8cm 3cm 3cm 7 m 5 m 3 m 2cm W= 6 kN/m 6cm A D B 2cm 7TITT TITIT Figure 2 1) Replace the support C with the reaction force Rc, and using static equilibrium find the reactions at point A and...
Question 3 Use discontinuity equations to develop the load function w(x) for the beam shown below....
Question 3 Use discontinuity equations to develop the load function w(x) for the beam shown below. Include the beam reaction in this expression. Integrate w(x) to determine V(x), and M(x), Use these functions to plot the shear-force and bending-moment diagrams using excel. Include table data obtained Determine the bending moment M in the beam at the point located 2.12 m to the left of point C 2.0 kN/m 5.0 kN/m 3 m 5 m 4.70 kN 14.30 kN
QUESTION 4 (25 marks) A simply supported beam is loaded by an uniform distributed load, wkN/m, over the span of the beam, L, as shown in Figure Q4. (a) Determine the end reactions at point A and...
QUESTION 4 (25 marks) A simply supported beam is loaded by an uniform distributed load, wkN/m, over the span of the beam, L, as shown in Figure Q4. (a) Determine the end reactions at point A and B in terms of w and L. (4 marks) (b) At an arbitrary point, x, express the internal mom (c) Show that the deflection curve of the beam under the loading situation is ent, M(x), in x, w, and L. (5 marks) 24EI...
Problem 3: The statically indeterminate propped cantilever beam is supported by a roller at A and...
Problem 3: The statically indeterminate propped cantilever beam is supported by a roller at A and is fixed at B. The beam is subject a uniformly distributed load and concentrated moment as shown. E is 29000 ksi and 1 is 400 in Determine the equation of the moment as a function of x. b) a) Determine the equations of the beam slope and deflection as a functions ofx (do not substitute the values of E and I c) Find slope...
The beam is shown in the figure below. Use the slope-deflection method. The support Ais pinned,...
The beam is shown in the figure below. Use the slope-deflection method. The support Ais pinned, support B is a roller, and support C is fixed. Assume El = 21537 kNm2. The support at B settles by 73 mm (downwards). The segment AB is subjected to a uniformly distributed load w= 11 kN/m. The segment BC is subjected to a point load P = 91 KN. Enter the digit one in the answer box. The link will be provided on...
2. The governing differential equation that relates the deflection y of a beam to the load w ia where both y and w are are functions of r. In the above equation, E is the modulus of elasticity and I is the moment of inertia of the beam. For the beam and loading shown in the figure, first de m, E = 200 GPa, 1 = 100 × 106 mm4 and uo 100 kN/m and determine the maximum deflection. Note...
Problem 2 Consider a simply supported symmetric I beam ABCD carrying a uniformly distributed load w and a concentrated load F as shown in Figure 2. Young's modulus of the beam is 200 GPa F- 8 kNN 8cm 3cm 3cm w- 6 kN/m 6cm 2cm Figure 2 1) Replace the support C with the reaction force Rc, and using static equilibrium find the reactions at point A and B in terms of Ro 2) Using the boundary conditions, calculate the...
4N Problem 6. The beam shown is loaded with a linear distributed load for the left half and a constant distributed load for the right. At the center a 4 N load is applied. 6 N/m a) Use equilibrium to find the shear and moment equations for the beam. b) Draw the shear and moment diagrams for the beam. c) Integrate your answers to find the deflection of the beam. Leave your final answer as a piecewise function. (IE can...
Q2. A simply supported beam AB (Figure 2) supports a uniformly distributed load of q = 18kN/m and a concentrated load of P = 23kN at the centre. Consider length of the beam, L = 3m, Young's modulus, E = 200GPa and moment of inertial, I = 30 x 10 mm-. Assume the deflection of the beam can be expressed by elastic curve equations of the form: y(x) = Ax4 + Bx3 + Cx2 + Dx + E. 1) Sketch...
(2) A simply supported beam of flexural rigidity El carries a constant uniformly distributed load of intensity p per unit length as shown Figure 2 below. Assume the deflection shape to be a polynomial in x, and is given by v (x) = a., + as+ a2 x, where ao, a.呙are constants to be determined. (a) State the boundary conditions for the deflection equation. Using the boundary conditions stated in (a) and the Rayleigh-Ritz method, determine (b) the constants a,...
Problem 2 Consider a simply supported symmetric I beam ABCD carrying a uniformly distributed load w and a concentrated load F as shown in Figure 2. Young's modulus of the beam is 200 GPa. F 8 kN 8cm 3cm 3cm 7 m 5 m 3 m 2cm W= 6 kN/m 6cm A D B 2cm 7TITT TITIT Figure 2 1) Replace the support C with the reaction force Rc, and using static equilibrium find the reactions at point A and...
Question 3 Use discontinuity equations to develop the load function w(x) for the beam shown below. Include the beam reaction in this expression. Integrate w(x) to determine V(x), and M(x), Use these functions to plot the shear-force and bending-moment diagrams using excel. Include table data obtained Determine the bending moment M in the beam at the point located 2.12 m to the left of point C 2.0 kN/m 5.0 kN/m 3 m 5 m 4.70 kN 14.30 kN
QUESTION 4 (25 marks) A simply supported beam is loaded by an uniform distributed load, wkN/m, over the span of the beam, L, as shown in Figure Q4. (a) Determine the end reactions at point A and B in terms of w and L. (4 marks) (b) At an arbitrary point, x, express the internal mom (c) Show that the deflection curve of the beam under the loading situation is ent, M(x), in x, w, and L. (5 marks) 24EI...
Problem 3: The statically indeterminate propped cantilever beam is supported by a roller at A and is fixed at B. The beam is subject a uniformly distributed load and concentrated moment as shown. E is 29000 ksi and 1 is 400 in Determine the equation of the moment as a function of x. b) a) Determine the equations of the beam slope and deflection as a functions ofx (do not substitute the values of E and I c) Find slope...
The beam is shown in the figure below. Use the slope-deflection method. The support Ais pinned, support B is a roller, and support C is fixed. Assume El = 21537 kNm2. The support at B settles by 73 mm (downwards). The segment AB is subjected to a uniformly distributed load w= 11 kN/m. The segment BC is subjected to a point load P = 91 KN. Enter the digit one in the answer box. The link will be provided on...
